| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_189T01_9000003614_24616cztM0_level2.evt | modeM0/AS1T03_189T01_9000003614_24616cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,792,320 | 80,547,840 |
| Size | 476.6 MB | 76.8 MB |
| Events in quadrant A | 3,272,977 | 508,202 |
| Events in quadrant B | 4,051,098 | 492,627 |
| Events in quadrant C | 3,519,711 | 487,226 |
| Events in quadrant D | 3,828,925 | 475,236 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13961 | 2 |
| B | 0 | 16364 | 2 |
| C | 0 | 14678 | 2 |
| D | 0 | 15858 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6825 | 71 | 1.040293% |
| B | 6824 | 464 | 6.799531% |
| C | 6824 | 168 | 2.461899% |
| D | 6825 | 143 | 2.095238% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8470 | 6827 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8469 | 6826 | 73 | 73 | 0.86% | 1.07% |  |
| C | 8469 | 6826 | 40 | 40 | 0.47% | 0.59% |  |
| D | 8470 | 6827 | 75 | 75 | 0.89% | 1.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9774 | 52.38 | 845 | 826 | 170.8 |
| A | 3 | 137 | 7911 | 41.47 | 845 | 826 | 170.8 |
| A | 0 | 226 | 7122 | 36.85 | 845 | 826 | 170.8 |
| B | 3 | 64 | 787632 | 4986.59 | 822 | 797 | 157.8 |
| B | 7 | 202 | 30646 | 189.17 | 822 | 797 | 157.8 |
| B | 12 | 111 | 20050 | 122.02 | 822 | 797 | 157.8 |
| C | 9 | 54 | 232341 | 1235.6 | 803 | 809 | 187.4 |
| C | 14 | 238 | 126599 | 671.29 | 803 | 809 | 187.4 |
| C | 7 | 247 | 19135 | 97.8 | 803 | 809 | 187.4 |
| D | 8 | 195 | 340567 | 1722.44 | 812 | 789 | 197.3 |
| D | 7 | 238 | 235843 | 1191.56 | 812 | 789 | 197.3 |
| D | 10 | 1 | 115551 | 581.76 | 812 | 789 | 197.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
