| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_012T06_9000003616_24630cztM0_level2.evt | modeM0/AS1C05_012T06_9000003616_24630cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,318,636,800 | 187,390,080 |
| Size | 1.2 GB | 178.7 MB |
| Events in quadrant A | 5,152,467 | 1,315,054 |
| Events in quadrant B | 5,768,237 | 1,331,885 |
| Events in quadrant C | 21,067,024 | 1,007,616 |
| Events in quadrant D | 7,188,426 | 1,239,553 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22724 | 3 |
| B | 0 | 24355 | 2 |
| C | 0 | 70304 | 2 |
| D | 0 | 29137 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 232 | 0 |
| B | 0 | 232 | 0 |
| C | 0 | 232 | 0 |
| D | 0 | 232 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 11242 | 45 | 0.400285% |
| B | 11242 | 146 | 1.298701% |
| C | 11242 | 6804 | 60.523039% |
| D | 11242 | 506 | 4.500978% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 12738 | 11244 | 0 | 0 | 0.00% | 0.00% |  |
| B | 12738 | 11244 | 55 | 55 | 0.43% | 0.49% |  |
| C | 12738 | 11243 | 5528 | 5528 | 43.40% | 49.17% |  |
| D | 12738 | 11244 | 275 | 275 | 2.16% | 2.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 26661 | 95.84 | 1328 | 1301 | 264.6 |
| A | 13 | 254 | 18311 | 64.29 | 1328 | 1301 | 264.6 |
| A | 3 | 137 | 12567 | 42.58 | 1328 | 1301 | 264.6 |
| B | 3 | 64 | 497297 | 1981.99 | 1317 | 1283 | 250.3 |
| B | 5 | 172 | 53843 | 210.02 | 1317 | 1283 | 250.3 |
| B | 12 | 111 | 30994 | 118.72 | 1317 | 1283 | 250.3 |
| C | 7 | 247 | 16620456 | 67372.68 | 1073 | 1081 | 246.7 |
| C | 14 | 238 | 163750 | 659.44 | 1073 | 1081 | 246.7 |
| C | 7 | 226 | 48609 | 192.67 | 1073 | 1081 | 246.7 |
| D | 1 | 52 | 1708992 | 5556.49 | 1269 | 1229 | 307.3 |
| D | 9 | 1 | 273330 | 885.32 | 1269 | 1229 | 307.3 |
| D | 8 | 195 | 254598 | 824.38 | 1269 | 1229 | 307.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
