| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_191T01_9000003618_24679cztM0_level2.evt | modeM0/AS1T03_191T01_9000003618_24679cztM0_level2_quad_clean.evt |
| Size (bytes) | 482,270,400 | 135,313,920 |
| Size | 459.9 MB | 129.0 MB |
| Events in quadrant A | 3,175,675 | 952,773 |
| Events in quadrant B | 3,201,337 | 952,748 |
| Events in quadrant C | 3,088,662 | 903,101 |
| Events in quadrant D | 4,734,010 | 871,876 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13185 | 1 |
| B | 0 | 13271 | 1 |
| C | 0 | 12966 | 1 |
| D | 0 | 18281 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5982 | 95 | 1.588098% |
| B | 5982 | 81 | 1.354062% |
| C | 5982 | 116 | 1.939151% |
| D | 5982 | 418 | 6.987630% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7272 | 5982 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7272 | 5982 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7272 | 5982 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7272 | 5982 | 330 | 330 | 4.54% | 5.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 31309 | 190.2 | 812 | 798 | 160.4 |
| A | 10 | 255 | 13535 | 79.4 | 812 | 798 | 160.4 |
| A | 13 | 254 | 9585 | 54.78 | 812 | 798 | 160.4 |
| B | 0 | 189 | 105608 | 725.35 | 789 | 772 | 144.5 |
| B | 12 | 111 | 16803 | 110.92 | 789 | 772 | 144.5 |
| B | 11 | 111 | 15332 | 100.74 | 789 | 772 | 144.5 |
| C | 14 | 238 | 124736 | 715.79 | 757 | 762 | 173.2 |
| C | 2 | 16 | 6682 | 34.18 | 757 | 762 | 173.2 |
| C | 3 | 233 | 5845 | 29.35 | 757 | 762 | 173.2 |
| D | 1 | 52 | 1273168 | 6931.78 | 769 | 751 | 183.6 |
| D | 8 | 195 | 534900 | 2909.9 | 769 | 751 | 183.6 |
| D | 2 | 234 | 21616 | 113.67 | 769 | 751 | 183.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
