| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_191T01_9000003618_24691cztM0_level2.evt | modeM0/AS1T03_191T01_9000003618_24691cztM0_level2_quad_clean.evt |
| Size (bytes) | 547,107,840 | 136,805,760 |
| Size | 521.8 MB | 130.5 MB |
| Events in quadrant A | 3,264,660 | 946,706 |
| Events in quadrant B | 3,295,404 | 962,315 |
| Events in quadrant C | 3,396,727 | 915,885 |
| Events in quadrant D | 6,169,813 | 863,198 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13843 | 2 |
| B | 0 | 13994 | 2 |
| C | 0 | 14415 | 2 |
| D | 0 | 22657 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6533 | 59 | 0.903107% |
| B | 6533 | 66 | 1.010256% |
| C | 6533 | 114 | 1.744987% |
| D | 6533 | 684 | 10.469922% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7633 | 6533 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7633 | 6533 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7633 | 6533 | 4 | 4 | 0.05% | 0.06% |  |
| D | 7633 | 6533 | 595 | 595 | 7.80% | 9.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11330 | 62.81 | 844 | 829 | 167.2 |
| A | 0 | 226 | 7338 | 38.93 | 844 | 829 | 167.2 |
| A | 3 | 137 | 7255 | 38.44 | 844 | 829 | 167.2 |
| B | 12 | 111 | 18761 | 114.81 | 836 | 817 | 156.3 |
| B | 11 | 111 | 16667 | 101.41 | 836 | 817 | 156.3 |
| B | 14 | 111 | 15475 | 93.79 | 836 | 817 | 156.3 |
| C | 14 | 238 | 131549 | 698.91 | 814 | 820 | 187.0 |
| C | 7 | 247 | 33634 | 175.43 | 814 | 820 | 187.0 |
| C | 2 | 16 | 25782 | 133.45 | 814 | 820 | 187.0 |
| D | 1 | 52 | 3006350 | 15512.18 | 805 | 782 | 193.8 |
| D | 8 | 195 | 61796 | 314.9 | 805 | 782 | 193.8 |
| D | 10 | 199 | 31794 | 160.06 | 805 | 782 | 193.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
