| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_191T01_9000003618_24695cztM0_level2.evt | modeM0/AS1T03_191T01_9000003618_24695cztM0_level2_quad_clean.evt |
| Size (bytes) | 568,578,240 | 123,217,920 |
| Size | 542.2 MB | 117.5 MB |
| Events in quadrant A | 2,945,626 | 881,895 |
| Events in quadrant B | 4,154,095 | 855,175 |
| Events in quadrant C | 3,199,838 | 823,399 |
| Events in quadrant D | 6,520,538 | 759,093 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12341 | 1 |
| B | 0 | 16023 | 1 |
| C | 0 | 13172 | 1 |
| D | 0 | 23465 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5897 | 106 | 1.797524% |
| B | 5897 | 440 | 7.461421% |
| C | 5897 | 118 | 2.001017% |
| D | 5897 | 911 | 15.448533% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7122 | 5897 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7122 | 5897 | 267 | 267 | 3.75% | 4.53% |  |
| C | 7122 | 5897 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7122 | 5897 | 812 | 812 | 11.40% | 13.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9996 | 60.97 | 762 | 747 | 151.7 |
| A | 0 | 226 | 6784 | 39.79 | 762 | 747 | 151.7 |
| A | 3 | 137 | 6371 | 37.07 | 762 | 747 | 151.7 |
| B | 4 | 80 | 1242983 | 9068.04 | 731 | 716 | 137.0 |
| B | 0 | 189 | 18075 | 126.71 | 731 | 716 | 137.0 |
| B | 0 | 190 | 16880 | 117.99 | 731 | 716 | 137.0 |
| C | 7 | 247 | 296269 | 1813.28 | 707 | 712 | 163.0 |
| C | 14 | 238 | 116531 | 710.56 | 707 | 712 | 163.0 |
| C | 3 | 233 | 21227 | 125.86 | 707 | 712 | 163.0 |
| D | 1 | 52 | 2261758 | 13539.3 | 693 | 672 | 167.0 |
| D | 8 | 195 | 1566917 | 9378.62 | 693 | 672 | 167.0 |
| D | 12 | 233 | 33654 | 197.5 | 693 | 672 | 167.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
