| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_191T01_9000003618_24699cztM0_level2.evt | modeM0/AS1T03_191T01_9000003618_24699cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,615,680 | 143,861,760 |
| Size | 533.7 MB | 137.2 MB |
| Events in quadrant A | 3,547,343 | 984,599 |
| Events in quadrant B | 4,085,805 | 985,811 |
| Events in quadrant C | 3,953,140 | 938,675 |
| Events in quadrant D | 4,841,362 | 914,846 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15743 | 2 |
| B | 0 | 17194 | 2 |
| C | 0 | 16404 | 2 |
| D | 0 | 19508 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7669 | 75 | 0.977963% |
| B | 7669 | 192 | 2.503586% |
| C | 7669 | 97 | 1.264832% |
| D | 7669 | 274 | 3.572826% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7959 | 7669 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7959 | 7669 | 68 | 68 | 0.85% | 0.89% |  |
| C | 7959 | 7670 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7959 | 7670 | 225 | 225 | 2.83% | 2.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 13084 | 65.77 | 917 | 895 | 185.3 |
| A | 10 | 255 | 9530 | 46.59 | 917 | 895 | 185.3 |
| A | 3 | 137 | 8478 | 40.91 | 917 | 895 | 185.3 |
| B | 4 | 80 | 325065 | 1895.82 | 905 | 884 | 171.0 |
| B | 3 | 64 | 124869 | 725.07 | 905 | 884 | 171.0 |
| B | 0 | 189 | 44269 | 253.72 | 905 | 884 | 171.0 |
| C | 7 | 247 | 393546 | 1934.74 | 866 | 870 | 203.0 |
| C | 14 | 238 | 139415 | 682.62 | 866 | 870 | 203.0 |
| C | 3 | 233 | 18446 | 86.6 | 866 | 870 | 203.0 |
| D | 1 | 52 | 836077 | 3975.08 | 869 | 843 | 210.1 |
| D | 8 | 195 | 538721 | 2559.89 | 869 | 843 | 210.1 |
| D | 7 | 238 | 113430 | 535.83 | 869 | 843 | 210.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
