| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_194T01_9000003620_24732cztM0_level2.evt | modeM0/AS1T03_194T01_9000003620_24732cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,593,280 | 85,279,680 |
| Size | 464.1 MB | 81.3 MB |
| Events in quadrant A | 3,192,707 | 542,713 |
| Events in quadrant B | 3,264,231 | 548,934 |
| Events in quadrant C | 3,996,037 | 514,741 |
| Events in quadrant D | 3,823,058 | 503,328 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13762 | 2 |
| B | 0 | 13915 | 2 |
| C | 0 | 16464 | 2 |
| D | 0 | 16077 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6788 | 19 | 0.279906% |
| B | 6788 | 25 | 0.368297% |
| C | 6788 | 81 | 1.193282% |
| D | 6788 | 123 | 1.812021% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7723 | 6788 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7723 | 6788 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7723 | 6788 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7723 | 6788 | 106 | 106 | 1.37% | 1.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9948 | 54.95 | 826 | 809 | 166.3 |
| A | 10 | 255 | 9559 | 52.61 | 826 | 809 | 166.3 |
| A | 3 | 137 | 7732 | 41.63 | 826 | 809 | 166.3 |
| B | 12 | 111 | 19880 | 120.73 | 820 | 798 | 158.1 |
| B | 11 | 111 | 17784 | 107.47 | 820 | 798 | 158.1 |
| B | 14 | 111 | 16445 | 99.0 | 820 | 798 | 158.1 |
| C | 7 | 247 | 743336 | 3992.75 | 790 | 796 | 186.0 |
| C | 14 | 238 | 124063 | 662.83 | 790 | 796 | 186.0 |
| C | 2 | 16 | 29079 | 152.08 | 790 | 796 | 186.0 |
| D | 1 | 52 | 375569 | 1944.83 | 793 | 769 | 192.7 |
| D | 7 | 238 | 162944 | 841.52 | 793 | 769 | 192.7 |
| D | 12 | 233 | 121495 | 626.45 | 793 | 769 | 192.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
