| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_018T08_9000003622_24743cztM0_level2.evt | modeM0/AS1A07_018T08_9000003622_24743cztM0_level2_quad_clean.evt |
| Size (bytes) | 881,844,480 | 83,453,760 |
| Size | 841.0 MB | 79.6 MB |
| Events in quadrant A | 3,849,605 | 533,642 |
| Events in quadrant B | 4,518,622 | 529,949 |
| Events in quadrant C | 11,991,689 | 412,350 |
| Events in quadrant D | 5,816,607 | 504,570 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16445 | 3 |
| B | 0 | 18476 | 3 |
| C | 0 | 41070 | 3 |
| D | 0 | 22671 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7845 | 190 | 2.421925% |
| B | 7846 | 413 | 5.263829% |
| C | 7845 | 3400 | 43.339707% |
| D | 7845 | 378 | 4.818356% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8479 | 7845 | 4 | 4 | 0.05% | 0.05% |  |
| B | 8480 | 7845 | 159 | 159 | 1.88% | 2.03% |  |
| C | 8479 | 7844 | 2382 | 2382 | 28.09% | 30.37% |  |
| D | 8479 | 7844 | 162 | 162 | 1.91% | 2.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 17491 | 81.72 | 993 | 970 | 202.2 |
| A | 13 | 254 | 13155 | 60.27 | 993 | 970 | 202.2 |
| A | 3 | 137 | 8925 | 39.35 | 993 | 970 | 202.2 |
| B | 3 | 64 | 496894 | 2677.7 | 970 | 946 | 185.2 |
| B | 0 | 190 | 91125 | 486.89 | 970 | 946 | 185.2 |
| B | 0 | 189 | 33657 | 176.61 | 970 | 946 | 185.2 |
| C | 7 | 247 | 8502816 | 45317.94 | 802 | 804 | 187.6 |
| C | 10 | 91 | 183796 | 975.4 | 802 | 804 | 187.6 |
| C | 14 | 238 | 122378 | 648.02 | 802 | 804 | 187.6 |
| D | 8 | 195 | 976128 | 4182.12 | 955 | 924 | 233.2 |
| D | 1 | 52 | 740350 | 3170.99 | 955 | 924 | 233.2 |
| D | 12 | 233 | 277117 | 1184.44 | 955 | 924 | 233.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
