| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_147T01_9000003624_24782cztM0_level2.evt | modeM0/AS1A07_147T01_9000003624_24782cztM0_level2_quad_clean.evt |
| Size (bytes) | 583,992,000 | 90,181,440 |
| Size | 556.9 MB | 86.0 MB |
| Events in quadrant A | 3,829,523 | 584,656 |
| Events in quadrant B | 5,460,120 | 567,119 |
| Events in quadrant C | 3,846,170 | 551,364 |
| Events in quadrant D | 4,079,676 | 543,458 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15309 | 0 |
| B | 0 | 20605 | 0 |
| C | 0 | 15398 | 0 |
| D | 0 | 16329 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6943 | 196 | 2.822987% |
| B | 6942 | 804 | 11.581677% |
| C | 6942 | 215 | 3.097090% |
| D | 6943 | 163 | 2.347688% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9438 | 6945 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9437 | 6944 | 379 | 379 | 4.02% | 5.46% |  |
| C | 9437 | 6944 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9438 | 6945 | 8 | 8 | 0.08% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9756 | 44.69 | 991 | 972 | 196.5 |
| A | 3 | 137 | 8728 | 39.46 | 991 | 972 | 196.5 |
| A | 0 | 226 | 8535 | 38.48 | 991 | 972 | 196.5 |
| B | 3 | 64 | 1745915 | 9679.65 | 943 | 920 | 180.3 |
| B | 12 | 111 | 22383 | 119.05 | 943 | 920 | 180.3 |
| B | 11 | 111 | 20248 | 107.21 | 943 | 920 | 180.3 |
| C | 14 | 238 | 147582 | 686.01 | 928 | 938 | 213.8 |
| C | 8 | 208 | 35062 | 159.64 | 928 | 938 | 213.8 |
| C | 1 | 16 | 24642 | 110.89 | 928 | 938 | 213.8 |
| D | 8 | 195 | 400628 | 1753.8 | 943 | 917 | 227.9 |
| D | 1 | 52 | 105093 | 457.09 | 943 | 917 | 227.9 |
| D | 2 | 234 | 23999 | 101.28 | 943 | 917 | 227.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
