| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_197T01_9000003626_24811cztM0_level2.evt | modeM0/AS1T03_197T01_9000003626_24811cztM0_level2_quad_clean.evt |
| Size (bytes) | 441,385,920 | 70,899,840 |
| Size | 420.9 MB | 67.6 MB |
| Events in quadrant A | 3,116,024 | 441,611 |
| Events in quadrant B | 3,328,832 | 442,940 |
| Events in quadrant C | 3,051,258 | 422,565 |
| Events in quadrant D | 3,462,071 | 418,939 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12550 | 1 |
| B | 0 | 13282 | 1 |
| C | 0 | 12449 | 1 |
| D | 0 | 13931 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6024 | 77 | 1.278220% |
| B | 6025 | 147 | 2.439834% |
| C | 6025 | 101 | 1.676349% |
| D | 6025 | 77 | 1.278008% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7209 | 6025 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7210 | 6026 | 32 | 32 | 0.44% | 0.53% |  |
| C | 7210 | 6026 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7210 | 6026 | 22 | 22 | 0.31% | 0.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 23417 | 141.79 | 802 | 789 | 159.6 |
| A | 13 | 254 | 8828 | 50.37 | 802 | 789 | 159.6 |
| A | 3 | 137 | 7201 | 40.18 | 802 | 789 | 159.6 |
| B | 3 | 64 | 180780 | 1225.43 | 781 | 764 | 146.9 |
| B | 0 | 190 | 24082 | 158.73 | 781 | 764 | 146.9 |
| B | 10 | 249 | 22443 | 147.58 | 781 | 764 | 146.9 |
| C | 14 | 238 | 121098 | 696.98 | 750 | 755 | 172.7 |
| C | 13 | 61 | 5196 | 25.72 | 750 | 755 | 172.7 |
| C | 8 | 208 | 4377 | 20.98 | 750 | 755 | 172.7 |
| D | 8 | 195 | 394417 | 2117.15 | 772 | 751 | 185.9 |
| D | 1 | 52 | 123318 | 659.17 | 772 | 751 | 185.9 |
| D | 2 | 234 | 21533 | 111.76 | 772 | 751 | 185.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
