| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T06_9000003636_24854cztM0_level2.evt | modeM0/AS1A08_003T06_9000003636_24854cztM0_level2_quad_clean.evt |
| Size (bytes) | 537,347,520 | 68,273,280 |
| Size | 512.5 MB | 65.1 MB |
| Events in quadrant A | 3,898,058 | 410,195 |
| Events in quadrant B | 3,613,580 | 423,949 |
| Events in quadrant C | 4,204,700 | 388,811 |
| Events in quadrant D | 4,109,976 | 383,896 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15293 | 2 |
| B | 0 | 14391 | 2 |
| C | 0 | 16845 | 2 |
| D | 0 | 16466 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6601 | 176 | 2.666263% |
| B | 6601 | 113 | 1.711862% |
| C | 6601 | 133 | 2.014846% |
| D | 6601 | 113 | 1.711862% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7896 | 6602 | 74 | 74 | 0.94% | 1.12% |  |
| B | 7896 | 6602 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7896 | 6602 | 9 | 9 | 0.11% | 0.14% |  |
| D | 7896 | 6602 | 64 | 64 | 0.81% | 0.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 366276 | 2005.65 | 916 | 900 | 182.2 |
| A | 13 | 254 | 9422 | 46.78 | 916 | 900 | 182.2 |
| A | 3 | 137 | 7832 | 38.05 | 916 | 900 | 182.2 |
| B | 12 | 111 | 20631 | 114.95 | 914 | 894 | 171.7 |
| B | 11 | 111 | 18780 | 104.17 | 914 | 894 | 171.7 |
| B | 14 | 111 | 18159 | 100.55 | 914 | 894 | 171.7 |
| C | 7 | 247 | 591581 | 2980.75 | 860 | 868 | 198.2 |
| C | 14 | 238 | 140731 | 705.75 | 860 | 868 | 198.2 |
| C | 2 | 16 | 57509 | 285.81 | 860 | 868 | 198.2 |
| D | 1 | 52 | 481349 | 2280.8 | 869 | 842 | 210.7 |
| D | 12 | 218 | 277143 | 1311.5 | 869 | 842 | 210.7 |
| D | 8 | 195 | 58649 | 274.39 | 869 | 842 | 210.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
