| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_027T02_9000003640_24863cztM0_level2.evt | modeM0/AS1A07_027T02_9000003640_24863cztM0_level2_quad_clean.evt |
| Size (bytes) | 523,552,320 | 91,929,600 |
| Size | 499.3 MB | 87.7 MB |
| Events in quadrant A | 4,322,660 | 590,206 |
| Events in quadrant B | 3,334,434 | 602,670 |
| Events in quadrant C | 3,383,473 | 573,649 |
| Events in quadrant D | 4,371,809 | 561,305 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17105 | 2 |
| B | 0 | 14128 | 2 |
| C | 0 | 14131 | 2 |
| D | 0 | 17542 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6543 | 174 | 2.659331% |
| B | 6543 | 62 | 0.947578% |
| C | 6543 | 113 | 1.727037% |
| D | 6543 | 152 | 2.323093% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7633 | 6544 | 64 | 64 | 0.84% | 0.98% |  |
| B | 7633 | 6544 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7633 | 6544 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7633 | 6544 | 97 | 97 | 1.27% | 1.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 1137362 | 6952.36 | 825 | 809 | 163.5 |
| A | 13 | 254 | 9764 | 54.78 | 825 | 809 | 163.5 |
| A | 3 | 137 | 7592 | 41.49 | 825 | 809 | 163.5 |
| B | 0 | 189 | 23159 | 141.09 | 826 | 805 | 158.4 |
| B | 12 | 0 | 20917 | 126.94 | 826 | 805 | 158.4 |
| B | 12 | 111 | 19278 | 116.6 | 826 | 805 | 158.4 |
| C | 14 | 238 | 128883 | 691.03 | 799 | 804 | 185.3 |
| C | 2 | 16 | 91139 | 487.39 | 799 | 804 | 185.3 |
| C | 7 | 247 | 38895 | 205.51 | 799 | 804 | 185.3 |
| D | 12 | 218 | 860584 | 4447.4 | 805 | 781 | 193.3 |
| D | 8 | 195 | 243599 | 1256.0 | 805 | 781 | 193.3 |
| D | 1 | 52 | 162355 | 835.75 | 805 | 781 | 193.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
