| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_027T16_9000003642_24884cztM0_level2.evt | modeM0/AS1A07_027T16_9000003642_24884cztM0_level2_quad_clean.evt |
| Size (bytes) | 632,750,400 | 89,700,480 |
| Size | 603.4 MB | 85.5 MB |
| Events in quadrant A | 3,817,497 | 582,305 |
| Events in quadrant B | 3,041,472 | 601,029 |
| Events in quadrant C | 7,983,956 | 532,476 |
| Events in quadrant D | 3,900,110 | 567,376 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15260 | 1 |
| B | 0 | 12856 | 1 |
| C | 0 | 27831 | 1 |
| D | 0 | 15555 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6201 | 131 | 2.112562% |
| B | 6202 | 66 | 1.064173% |
| C | 6202 | 1933 | 31.167365% |
| D | 6202 | 148 | 2.386327% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7241 | 6202 | 78 | 78 | 1.08% | 1.26% |  |
| B | 7242 | 6203 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7242 | 6203 | 1591 | 1591 | 21.97% | 25.65% |  |
| D | 7242 | 6203 | 86 | 86 | 1.19% | 1.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 836877 | 5373.53 | 773 | 759 | 155.6 |
| A | 13 | 254 | 9571 | 56.63 | 773 | 759 | 155.6 |
| A | 3 | 137 | 6731 | 38.38 | 773 | 759 | 155.6 |
| B | 12 | 111 | 17535 | 115.47 | 767 | 747 | 145.4 |
| B | 11 | 111 | 15855 | 103.91 | 767 | 747 | 145.4 |
| B | 14 | 111 | 14292 | 93.16 | 767 | 747 | 145.4 |
| C | 7 | 247 | 5318343 | 35125.31 | 651 | 658 | 151.4 |
| C | 14 | 238 | 102030 | 669.6 | 651 | 658 | 151.4 |
| C | 7 | 226 | 16093 | 101.95 | 651 | 658 | 151.4 |
| D | 1 | 52 | 676470 | 3659.25 | 765 | 743 | 184.7 |
| D | 8 | 195 | 288923 | 1560.58 | 765 | 743 | 184.7 |
| D | 7 | 238 | 37529 | 199.21 | 765 | 743 | 184.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
