| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T09_9000003644_24887cztM0_level2.evt | modeM0/AS1A08_003T09_9000003644_24887cztM0_level2_quad_clean.evt |
| Size (bytes) | 194,054,400 | 20,070,720 |
| Size | 185.1 MB | 19.1 MB |
| Events in quadrant A | 1,901,913 | 113,286 |
| Events in quadrant B | 1,106,745 | 121,104 |
| Events in quadrant C | 1,257,298 | 114,198 |
| Events in quadrant D | 1,470,501 | 110,829 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6965 | 2 |
| B | 0 | 4476 | 2 |
| C | 0 | 4953 | 2 |
| D | 0 | 5772 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2029 | 481 | 23.706259% |
| B | 2029 | 171 | 8.427797% |
| C | 2029 | 225 | 11.089207% |
| D | 2029 | 161 | 7.934943% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2189 | 2032 | 187 | 187 | 8.54% | 9.20% |  |
| B | 2189 | 2032 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2189 | 2032 | 0 | 0 | 0.00% | 0.00% |  |
| D | 2189 | 2032 | 5 | 5 | 0.23% | 0.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 865336 | 15476.22 | 265 | 258 | 55.9 |
| A | 4 | 2 | 4226 | 70.99 | 265 | 258 | 55.9 |
| A | 12 | 96 | 4204 | 70.59 | 265 | 258 | 55.9 |
| B | 12 | 111 | 7199 | 120.45 | 278 | 269 | 57.5 |
| B | 4 | 173 | 6718 | 112.09 | 278 | 269 | 57.5 |
| B | 11 | 111 | 6671 | 111.27 | 278 | 269 | 57.5 |
| C | 7 | 247 | 181236 | 2802.31 | 265 | 265 | 64.6 |
| C | 14 | 238 | 41767 | 642.65 | 265 | 265 | 64.6 |
| C | 13 | 61 | 1782 | 23.49 | 265 | 265 | 64.6 |
| D | 8 | 195 | 256207 | 3641.91 | 276 | 267 | 70.3 |
| D | 7 | 238 | 96491 | 1369.22 | 276 | 267 | 70.3 |
| D | 1 | 52 | 66913 | 948.34 | 276 | 267 | 70.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
