| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T09_9000003644_24892cztM0_level2.evt | modeM0/AS1A08_003T09_9000003644_24892cztM0_level2_quad_clean.evt |
| Size (bytes) | 448,407,360 | 90,835,200 |
| Size | 427.6 MB | 86.6 MB |
| Events in quadrant A | 3,096,564 | 586,907 |
| Events in quadrant B | 3,159,296 | 598,699 |
| Events in quadrant C | 3,336,593 | 564,724 |
| Events in quadrant D | 3,551,548 | 552,816 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13339 | 2 |
| B | 0 | 13457 | 2 |
| C | 0 | 13912 | 2 |
| D | 0 | 14786 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6417 | 43 | 0.670095% |
| B | 6417 | 44 | 0.685679% |
| C | 6418 | 100 | 1.558118% |
| D | 6418 | 42 | 0.654409% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8472 | 6419 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8472 | 6419 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8473 | 6420 | 1 | 1 | 0.01% | 0.02% |  |
| D | 8473 | 6420 | 4 | 4 | 0.05% | 0.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10112 | 57.97 | 803 | 785 | 160.9 |
| A | 3 | 137 | 7527 | 41.91 | 803 | 785 | 160.9 |
| A | 0 | 226 | 6820 | 37.51 | 803 | 785 | 160.9 |
| B | 12 | 111 | 18879 | 117.55 | 801 | 781 | 154.0 |
| B | 11 | 111 | 17018 | 105.46 | 801 | 781 | 154.0 |
| B | 14 | 111 | 15771 | 97.36 | 801 | 781 | 154.0 |
| C | 7 | 247 | 126005 | 688.0 | 772 | 776 | 182.0 |
| C | 14 | 238 | 121693 | 664.31 | 772 | 776 | 182.0 |
| C | 2 | 16 | 69885 | 379.68 | 772 | 776 | 182.0 |
| D | 8 | 195 | 232025 | 1227.56 | 780 | 755 | 188.4 |
| D | 2 | 244 | 149624 | 790.18 | 780 | 755 | 188.4 |
| D | 7 | 238 | 106163 | 559.49 | 780 | 755 | 188.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
