| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T18_9000003658_24978cztM0_level2.evt | modeM0/AS1A08_003T18_9000003658_24978cztM0_level2_quad_clean.evt |
| Size (bytes) | 355,550,400 | 53,976,960 |
| Size | 339.1 MB | 51.5 MB |
| Events in quadrant A | 2,138,348 | 341,765 |
| Events in quadrant B | 2,225,502 | 346,156 |
| Events in quadrant C | 2,220,281 | 327,634 |
| Events in quadrant D | 3,879,566 | 304,320 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 92 | 0 |
| B | 0 | 92 | 0 |
| C | 0 | 92 | 0 |
| D | 0 | 92 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9288 | 1 |
| B | 0 | 9445 | 1 |
| C | 0 | 9404 | 1 |
| D | 0 | 14553 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4463 | 52 | 1.165136% |
| B | 4463 | 53 | 1.187542% |
| C | 4463 | 75 | 1.680484% |
| D | 4463 | 351 | 7.864665% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5393 | 4464 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5393 | 4464 | 3 | 3 | 0.06% | 0.07% |  |
| C | 5393 | 4464 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5393 | 4464 | 264 | 264 | 4.90% | 5.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 6937 | 56.48 | 553 | 539 | 113.3 |
| A | 13 | 254 | 6020 | 48.39 | 553 | 539 | 113.3 |
| A | 3 | 137 | 4981 | 39.22 | 553 | 539 | 113.3 |
| B | 3 | 64 | 20254 | 185.22 | 550 | 536 | 106.5 |
| B | 10 | 251 | 17501 | 159.36 | 550 | 536 | 106.5 |
| B | 0 | 190 | 16446 | 149.45 | 550 | 536 | 106.5 |
| C | 14 | 238 | 83858 | 661.44 | 530 | 534 | 126.0 |
| C | 7 | 247 | 41580 | 325.83 | 530 | 534 | 126.0 |
| C | 2 | 16 | 14144 | 108.04 | 530 | 534 | 126.0 |
| D | 7 | 238 | 582007 | 4498.64 | 526 | 511 | 129.3 |
| D | 1 | 52 | 545140 | 4213.43 | 526 | 511 | 129.3 |
| D | 10 | 70 | 516701 | 3993.41 | 526 | 511 | 129.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
