| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T18_9000003658_24987cztM0_level2.evt | modeM0/AS1A08_003T18_9000003658_24987cztM0_level2_quad_clean.evt |
| Size (bytes) | 411,151,680 | 58,944,960 |
| Size | 392.1 MB | 56.2 MB |
| Events in quadrant A | 2,459,335 | 371,198 |
| Events in quadrant B | 2,438,015 | 376,224 |
| Events in quadrant C | 3,450,302 | 342,053 |
| Events in quadrant D | 3,764,929 | 344,903 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10446 | 1 |
| B | 0 | 10308 | 1 |
| C | 0 | 13482 | 1 |
| D | 0 | 14494 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4991 | 47 | 0.941695% |
| B | 4992 | 66 | 1.322115% |
| C | 4992 | 324 | 6.490385% |
| D | 4992 | 97 | 1.943109% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5871 | 4992 | 1 | 1 | 0.02% | 0.02% |  |
| B | 5872 | 4993 | 0 | 0 | 0.00% | 0.00% |  |
| C | 5872 | 4993 | 143 | 143 | 2.44% | 2.86% |  |
| D | 5872 | 4993 | 71 | 71 | 1.21% | 1.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 130 | 45249 | 351.73 | 623 | 608 | 126.9 |
| A | 6 | 16 | 13370 | 100.55 | 623 | 608 | 126.9 |
| A | 13 | 254 | 6726 | 48.2 | 623 | 608 | 126.9 |
| B | 12 | 111 | 14907 | 117.91 | 618 | 603 | 121.3 |
| B | 11 | 111 | 13691 | 107.88 | 618 | 603 | 121.3 |
| B | 14 | 111 | 12606 | 98.94 | 618 | 603 | 121.3 |
| C | 7 | 247 | 1004867 | 7285.6 | 585 | 590 | 137.8 |
| C | 14 | 238 | 93592 | 674.69 | 585 | 590 | 137.8 |
| C | 2 | 16 | 67038 | 482.05 | 585 | 590 | 137.8 |
| D | 7 | 238 | 1283041 | 8827.12 | 596 | 578 | 145.3 |
| D | 1 | 52 | 93751 | 641.3 | 596 | 578 | 145.3 |
| D | 2 | 244 | 75202 | 513.63 | 596 | 578 | 145.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
