| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_127T03_9000003662_24998cztM0_level2.evt | modeM0/AS1A07_127T03_9000003662_24998cztM0_level2_quad_clean.evt |
| Size (bytes) | 581,970,240 | 114,641,280 |
| Size | 555.0 MB | 109.3 MB |
| Events in quadrant A | 3,334,946 | 766,886 |
| Events in quadrant B | 3,506,458 | 794,354 |
| Events in quadrant C | 6,852,915 | 737,226 |
| Events in quadrant D | 3,512,364 | 741,753 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13775 | 2 |
| B | 0 | 14373 | 2 |
| C | 0 | 24854 | 2 |
| D | 0 | 14535 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6185 | 40 | 0.646726% |
| B | 6185 | 95 | 1.535974% |
| C | 6185 | 798 | 12.902183% |
| D | 6185 | 33 | 0.533549% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7590 | 6186 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7590 | 6186 | 15 | 15 | 0.20% | 0.24% |  |
| C | 7590 | 6186 | 235 | 235 | 3.10% | 3.80% |  |
| D | 7590 | 6186 | 1 | 1 | 0.01% | 0.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9225 | 48.8 | 864 | 849 | 171.6 |
| A | 0 | 226 | 7487 | 38.68 | 864 | 849 | 171.6 |
| A | 3 | 137 | 7322 | 37.71 | 864 | 849 | 171.6 |
| B | 4 | 80 | 73168 | 449.48 | 868 | 851 | 160.9 |
| B | 12 | 111 | 18700 | 110.94 | 868 | 851 | 160.9 |
| B | 11 | 111 | 16562 | 97.65 | 868 | 851 | 160.9 |
| C | 7 | 247 | 3430479 | 17952.44 | 828 | 838 | 191.0 |
| C | 14 | 238 | 132605 | 689.73 | 828 | 838 | 191.0 |
| C | 0 | 10 | 29861 | 151.92 | 828 | 838 | 191.0 |
| D | 7 | 238 | 117948 | 568.57 | 856 | 834 | 206.0 |
| D | 8 | 195 | 81042 | 389.4 | 856 | 834 | 206.0 |
| D | 2 | 244 | 67218 | 322.28 | 856 | 834 | 206.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
