| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_027T12_9000003664_25010cztM0_level2.evt | modeM0/AS1A07_027T12_9000003664_25010cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,449,280 | 97,856,640 |
| Size | 429.6 MB | 93.3 MB |
| Events in quadrant A | 3,257,108 | 638,427 |
| Events in quadrant B | 3,320,867 | 655,445 |
| Events in quadrant C | 3,379,617 | 617,585 |
| Events in quadrant D | 3,247,694 | 603,908 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13864 | 2 |
| B | 0 | 13923 | 2 |
| C | 0 | 14124 | 2 |
| D | 0 | 13937 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6427 | 56 | 0.871324% |
| B | 6427 | 68 | 1.058036% |
| C | 6426 | 114 | 1.774043% |
| D | 6426 | 47 | 0.731404% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7632 | 6428 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7632 | 6428 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7631 | 6427 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7631 | 6427 | 3 | 3 | 0.04% | 0.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 20117 | 115.88 | 840 | 823 | 166.5 |
| A | 13 | 254 | 9222 | 50.44 | 840 | 823 | 166.5 |
| A | 3 | 137 | 7365 | 39.29 | 840 | 823 | 166.5 |
| B | 0 | 190 | 27065 | 166.29 | 839 | 820 | 157.8 |
| B | 12 | 111 | 18983 | 115.08 | 839 | 820 | 157.8 |
| B | 11 | 111 | 17098 | 103.14 | 839 | 820 | 157.8 |
| C | 14 | 238 | 131538 | 687.4 | 810 | 816 | 190.2 |
| C | 7 | 247 | 71853 | 373.55 | 810 | 816 | 190.2 |
| C | 2 | 16 | 13785 | 68.2 | 810 | 816 | 190.2 |
| D | 8 | 195 | 92854 | 468.84 | 817 | 794 | 196.4 |
| D | 2 | 234 | 26971 | 133.31 | 817 | 794 | 196.4 |
| D | 10 | 70 | 23003 | 113.1 | 817 | 794 | 196.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
