| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_206T01_9000003672_25032cztM0_level2.evt | modeM0/AS1T03_206T01_9000003672_25032cztM0_level2_quad_clean.evt |
| Size (bytes) | 129,372,480 | 17,657,280 |
| Size | 123.4 MB | 16.8 MB |
| Events in quadrant A | 784,081 | 106,158 |
| Events in quadrant B | 782,006 | 111,032 |
| Events in quadrant C | 827,746 | 104,207 |
| Events in quadrant D | 1,415,432 | 97,051 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 32 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3228 | 0 |
| B | 0 | 3230 | 0 |
| C | 0 | 3334 | 0 |
| D | 0 | 5319 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1560 | 3 | 0.192308% |
| B | 1560 | 13 | 0.833333% |
| C | 1560 | 12 | 0.769231% |
| D | 1560 | 66 | 4.230769% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 1560 | 1560 | 0 | 0 | 0.00% | 0.00% |  |
| B | 1560 | 1560 | 0 | 0 | 0.00% | 0.00% |  |
| C | 1560 | 1560 | 1 | 1 | 0.06% | 0.06% |  |
| D | 1560 | 1560 | 38 | 38 | 2.44% | 2.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 208 | 8085 | 181.51 | 201 | 195 | 43.5 |
| A | 13 | 254 | 2141 | 44.77 | 201 | 195 | 43.5 |
| A | 3 | 137 | 1979 | 41.04 | 201 | 195 | 43.5 |
| B | 12 | 111 | 5057 | 120.46 | 198 | 193 | 40.4 |
| B | 11 | 111 | 4716 | 112.02 | 198 | 193 | 40.4 |
| B | 14 | 111 | 4177 | 98.67 | 198 | 193 | 40.4 |
| C | 7 | 247 | 32562 | 687.66 | 190 | 191 | 47.1 |
| C | 14 | 238 | 29513 | 622.89 | 190 | 191 | 47.1 |
| C | 0 | 239 | 12517 | 261.84 | 190 | 191 | 47.1 |
| D | 8 | 195 | 400881 | 8302.72 | 190 | 183 | 48.3 |
| D | 1 | 52 | 270512 | 5601.39 | 190 | 183 | 48.3 |
| D | 13 | 174 | 22868 | 470.04 | 190 | 183 | 48.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
