| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_085T03_9000003764_26054cztM0_level2.evt | modeM0/AS1A09_085T03_9000003764_26054cztM0_level2_quad_clean.evt |
| Size (bytes) | 543,893,760 | 106,640,640 |
| Size | 518.7 MB | 101.7 MB |
| Events in quadrant A | 3,072,954 | 747,817 |
| Events in quadrant B | 3,115,503 | 748,918 |
| Events in quadrant C | 3,080,240 | 704,572 |
| Events in quadrant D | 6,803,889 | 616,401 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12436 | 0 |
| B | 0 | 12605 | 0 |
| C | 0 | 12549 | 0 |
| D | 0 | 24224 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5891 | 61 | 1.035478% |
| B | 5892 | 71 | 1.205024% |
| C | 5892 | 95 | 1.612356% |
| D | 5892 | 1122 | 19.042770% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7211 | 5891 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7212 | 5892 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7212 | 5892 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7212 | 5892 | 1054 | 1054 | 14.61% | 17.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8772 | 50.92 | 796 | 783 | 156.9 |
| A | 0 | 226 | 6932 | 39.2 | 796 | 783 | 156.9 |
| A | 3 | 137 | 6449 | 36.12 | 796 | 783 | 156.9 |
| B | 0 | 190 | 30332 | 205.98 | 776 | 760 | 143.6 |
| B | 15 | 33 | 26749 | 181.02 | 776 | 760 | 143.6 |
| B | 12 | 111 | 16510 | 109.7 | 776 | 760 | 143.6 |
| C | 14 | 238 | 123003 | 730.91 | 738 | 743 | 167.3 |
| C | 3 | 233 | 67377 | 398.36 | 738 | 743 | 167.3 |
| C | 2 | 16 | 14391 | 81.59 | 738 | 743 | 167.3 |
| D | 1 | 52 | 3881894 | 22021.36 | 689 | 672 | 176.2 |
| D | 12 | 2 | 211779 | 1197.78 | 689 | 672 | 176.2 |
| D | 12 | 233 | 36322 | 202.27 | 689 | 672 | 176.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
