| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_142T01_9000003766_26059cztM0_level2.evt | modeM0/AS1A09_142T01_9000003766_26059cztM0_level2_quad_clean.evt |
| Size (bytes) | 731,047,680 | 101,954,880 |
| Size | 697.2 MB | 97.2 MB |
| Events in quadrant A | 3,486,814 | 698,111 |
| Events in quadrant B | 3,438,319 | 700,713 |
| Events in quadrant C | 3,409,717 | 668,306 |
| Events in quadrant D | 11,324,353 | 524,606 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14903 | 0 |
| B | 0 | 14880 | 0 |
| C | 0 | 14700 | 0 |
| D | 0 | 38505 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7102 | 75 | 1.056041% |
| B | 7103 | 105 | 1.478249% |
| C | 7102 | 125 | 1.760068% |
| D | 7102 | 2744 | 38.637004% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7282 | 7102 | 19 | 19 | 0.26% | 0.27% |  |
| B | 7283 | 7104 | 8 | 8 | 0.11% | 0.11% |  |
| C | 7282 | 7103 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7281 | 7101 | 2509 | 2509 | 34.46% | 35.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 113504 | 645.9 | 861 | 842 | 174.4 |
| A | 11 | 29 | 46030 | 259.07 | 861 | 842 | 174.4 |
| A | 13 | 254 | 10761 | 56.87 | 861 | 842 | 174.4 |
| B | 5 | 172 | 39833 | 236.59 | 855 | 831 | 164.8 |
| B | 0 | 190 | 24506 | 143.62 | 855 | 831 | 164.8 |
| B | 12 | 111 | 19270 | 111.85 | 855 | 831 | 164.8 |
| C | 14 | 238 | 130617 | 658.86 | 831 | 835 | 197.0 |
| C | 8 | 208 | 27451 | 135.12 | 831 | 835 | 197.0 |
| C | 3 | 233 | 9875 | 45.89 | 831 | 835 | 197.0 |
| D | 1 | 3 | 7584847 | 39889.61 | 736 | 718 | 190.1 |
| D | 7 | 38 | 570095 | 2994.7 | 736 | 718 | 190.1 |
| D | 1 | 52 | 139638 | 730.67 | 736 | 718 | 190.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
