| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_138T04_9000003776_26124cztM0_level2.evt | modeM0/AS1A09_138T04_9000003776_26124cztM0_level2_quad_clean.evt |
| Size (bytes) | 516,418,560 | 108,760,320 |
| Size | 492.5 MB | 103.7 MB |
| Events in quadrant A | 3,707,370 | 718,792 |
| Events in quadrant B | 3,295,472 | 747,181 |
| Events in quadrant C | 3,493,801 | 710,733 |
| Events in quadrant D | 4,704,234 | 665,881 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15284 | 0 |
| B | 0 | 13875 | 0 |
| C | 0 | 14434 | 0 |
| D | 0 | 18173 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6467 | 59 | 0.912324% |
| B | 6467 | 26 | 0.402041% |
| C | 6467 | 87 | 1.345291% |
| D | 6467 | 510 | 7.886191% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7632 | 6467 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7632 | 6467 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7632 | 6467 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7632 | 6467 | 463 | 463 | 6.07% | 7.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 494516 | 2967.08 | 833 | 817 | 166.4 |
| A | 13 | 254 | 10178 | 56.26 | 833 | 817 | 166.4 |
| A | 3 | 137 | 7491 | 40.11 | 833 | 817 | 166.4 |
| B | 12 | 111 | 19021 | 113.72 | 838 | 817 | 160.1 |
| B | 11 | 111 | 17281 | 102.85 | 838 | 817 | 160.1 |
| B | 14 | 111 | 15399 | 91.09 | 838 | 817 | 160.1 |
| C | 14 | 238 | 129500 | 672.64 | 818 | 827 | 191.3 |
| C | 2 | 16 | 94698 | 490.71 | 818 | 827 | 191.3 |
| C | 3 | 233 | 65938 | 340.37 | 818 | 827 | 191.3 |
| D | 7 | 80 | 1562001 | 8256.55 | 796 | 779 | 189.1 |
| D | 12 | 233 | 67315 | 351.88 | 796 | 779 | 189.1 |
| D | 1 | 52 | 37934 | 196.49 | 796 | 779 | 189.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
