| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_056T01_9000003824_26440cztM0_level2.evt | modeM0/AS1A09_056T01_9000003824_26440cztM0_level2_quad_clean.evt |
| Size (bytes) | 193,795,200 | 33,693,120 |
| Size | 184.8 MB | 32.1 MB |
| Events in quadrant A | 1,402,232 | 211,604 |
| Events in quadrant B | 1,348,508 | 217,601 |
| Events in quadrant C | 1,438,618 | 203,321 |
| Events in quadrant D | 1,502,014 | 201,889 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5756 | 0 |
| B | 0 | 5538 | 0 |
| C | 0 | 5845 | 0 |
| D | 0 | 6122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2577 | 45 | 1.746217% |
| B | 2576 | 43 | 1.669255% |
| C | 2576 | 59 | 2.290373% |
| D | 2576 | 67 | 2.600932% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3532 | 2578 | 7 | 7 | 0.20% | 0.27% |  |
| B | 3531 | 2576 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3531 | 2577 | 6 | 6 | 0.17% | 0.23% |  |
| D | 3531 | 2577 | 29 | 29 | 0.82% | 1.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 65853 | 935.91 | 342 | 335 | 70.0 |
| A | 12 | 16 | 10799 | 149.48 | 342 | 335 | 70.0 |
| A | 12 | 194 | 4048 | 53.04 | 342 | 335 | 70.0 |
| B | 0 | 190 | 15090 | 222.99 | 338 | 329 | 66.2 |
| B | 12 | 111 | 8129 | 117.83 | 338 | 329 | 66.2 |
| B | 0 | 183 | 7326 | 105.7 | 338 | 329 | 66.2 |
| C | 4 | 254 | 58318 | 747.92 | 324 | 325 | 77.5 |
| C | 3 | 233 | 54281 | 695.86 | 324 | 325 | 77.5 |
| C | 14 | 238 | 51925 | 665.47 | 324 | 325 | 77.5 |
| D | 11 | 176 | 190999 | 2414.9 | 325 | 315 | 79.0 |
| D | 1 | 52 | 62126 | 782.8 | 325 | 315 | 79.0 |
| D | 2 | 234 | 11710 | 144.31 | 325 | 315 | 79.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
