| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_243T01_9000003918_27207cztM0_level2.evt | modeM0/AS1T03_243T01_9000003918_27207cztM0_level2_quad_clean.evt |
| Size (bytes) | 527,823,360 | 80,354,880 |
| Size | 503.4 MB | 76.6 MB |
| Events in quadrant A | 3,353,845 | 500,327 |
| Events in quadrant B | 4,374,984 | 498,421 |
| Events in quadrant C | 3,364,292 | 485,104 |
| Events in quadrant D | 4,423,230 | 467,702 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14182 | 0 |
| B | 0 | 17152 | 0 |
| C | 0 | 14238 | 0 |
| D | 0 | 17589 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6912 | 66 | 0.954861% |
| B | 6912 | 262 | 3.790509% |
| C | 6912 | 108 | 1.562500% |
| D | 6912 | 172 | 2.488426% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7802 | 6913 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7802 | 6913 | 114 | 114 | 1.46% | 1.65% |  |
| C | 7802 | 6913 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7802 | 6913 | 112 | 112 | 1.44% | 1.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 12877 | 69.04 | 865 | 846 | 174.3 |
| A | 13 | 254 | 9537 | 49.87 | 865 | 846 | 174.3 |
| A | 3 | 137 | 8400 | 43.35 | 865 | 846 | 174.3 |
| B | 3 | 64 | 996898 | 6039.89 | 855 | 834 | 164.9 |
| B | 12 | 111 | 20578 | 119.72 | 855 | 834 | 164.9 |
| B | 11 | 111 | 18324 | 106.06 | 855 | 834 | 164.9 |
| C | 14 | 238 | 134005 | 683.09 | 827 | 830 | 195.0 |
| C | 13 | 61 | 5594 | 24.44 | 827 | 830 | 195.0 |
| C | 15 | 208 | 4469 | 18.67 | 827 | 830 | 195.0 |
| D | 1 | 52 | 661049 | 3301.59 | 827 | 809 | 200.0 |
| D | 15 | 0 | 250590 | 1249.05 | 827 | 809 | 200.0 |
| D | 12 | 17 | 156880 | 780.45 | 827 | 809 | 200.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
