| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_255T01_9000003922_27315cztM0_level2.evt | modeM0/AS1T03_255T01_9000003922_27315cztM0_level2_quad_clean.evt |
| Size (bytes) | 452,439,360 | 100,425,600 |
| Size | 431.5 MB | 95.8 MB |
| Events in quadrant A | 3,217,219 | 682,065 |
| Events in quadrant B | 3,321,330 | 678,284 |
| Events in quadrant C | 3,238,324 | 633,976 |
| Events in quadrant D | 3,519,354 | 629,641 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13186 | 0 |
| B | 0 | 13392 | 0 |
| C | 0 | 13217 | 0 |
| D | 0 | 14273 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5974 | 130 | 2.176096% |
| B | 5975 | 154 | 2.577406% |
| C | 5975 | 180 | 3.012552% |
| D | 5974 | 107 | 1.791095% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7259 | 5975 | 18 | 18 | 0.25% | 0.30% |  |
| B | 7260 | 5976 | 38 | 38 | 0.52% | 0.64% |  |
| C | 7260 | 5976 | 11 | 11 | 0.15% | 0.18% |  |
| D | 7259 | 5975 | 45 | 45 | 0.62% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 74095 | 449.09 | 815 | 803 | 163.2 |
| A | 13 | 254 | 9799 | 55.12 | 815 | 803 | 163.2 |
| A | 0 | 226 | 7066 | 38.38 | 815 | 803 | 163.2 |
| B | 5 | 172 | 113903 | 756.54 | 799 | 782 | 149.5 |
| B | 0 | 190 | 26430 | 171.53 | 799 | 782 | 149.5 |
| B | 3 | 64 | 21193 | 136.51 | 799 | 782 | 149.5 |
| C | 14 | 238 | 123869 | 697.82 | 756 | 763 | 176.4 |
| C | 15 | 208 | 111592 | 628.23 | 756 | 763 | 176.4 |
| C | 2 | 16 | 50155 | 279.97 | 756 | 763 | 176.4 |
| D | 2 | 250 | 280149 | 1416.98 | 774 | 757 | 197.2 |
| D | 1 | 52 | 158166 | 798.32 | 774 | 757 | 197.2 |
| D | 12 | 233 | 49003 | 244.69 | 774 | 757 | 197.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
