| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_257T01_9000003976_27642cztM0_level2.evt | modeM0/AS1T03_257T01_9000003976_27642cztM0_level2_quad_clean.evt |
| Size (bytes) | 558,259,200 | 83,787,840 |
| Size | 532.4 MB | 79.9 MB |
| Events in quadrant A | 3,147,852 | 545,859 |
| Events in quadrant B | 3,226,957 | 552,798 |
| Events in quadrant C | 2,961,259 | 526,276 |
| Events in quadrant D | 7,149,842 | 478,495 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13517 | 0 |
| B | 0 | 13667 | 0 |
| C | 0 | 12858 | 0 |
| D | 0 | 25526 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6211 | 75 | 1.207535% |
| B | 6211 | 121 | 1.948156% |
| C | 6211 | 96 | 1.545645% |
| D | 6211 | 1037 | 16.696184% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7160 | 6210 | 9 | 9 | 0.13% | 0.14% |  |
| B | 7161 | 6211 | 28 | 28 | 0.39% | 0.45% |  |
| C | 7160 | 6210 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7161 | 6211 | 1058 | 1058 | 14.77% | 17.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 209217 | 1380.27 | 754 | 736 | 151.0 |
| A | 13 | 248 | 17792 | 112.92 | 754 | 736 | 151.0 |
| A | 13 | 254 | 10572 | 65.12 | 754 | 736 | 151.0 |
| B | 10 | 245 | 114181 | 787.11 | 751 | 731 | 144.1 |
| B | 5 | 255 | 75094 | 515.93 | 751 | 731 | 144.1 |
| B | 15 | 32 | 39575 | 269.5 | 751 | 731 | 144.1 |
| C | 14 | 238 | 115785 | 675.43 | 724 | 727 | 170.3 |
| C | 3 | 233 | 10274 | 56.04 | 724 | 727 | 170.3 |
| C | 2 | 16 | 8050 | 42.99 | 724 | 727 | 170.3 |
| D | 7 | 80 | 3165103 | 18831.84 | 699 | 679 | 168.0 |
| D | 1 | 52 | 884346 | 5258.8 | 699 | 679 | 168.0 |
| D | 2 | 250 | 371578 | 2207.26 | 699 | 679 | 168.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
