| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_116T01_9000004082_28337cztM0_level2.evt | modeM0/AS1A10_116T01_9000004082_28337cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,611,200 | 92,554,560 |
| Size | 445.9 MB | 88.3 MB |
| Events in quadrant A | 2,964,105 | 614,839 |
| Events in quadrant B | 3,310,801 | 618,675 |
| Events in quadrant C | 2,973,161 | 580,738 |
| Events in quadrant D | 4,493,064 | 556,379 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12883 | 0 |
| B | 0 | 13843 | 0 |
| C | 0 | 12862 | 0 |
| D | 0 | 17495 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6190 | 46 | 0.743134% |
| B | 6191 | 131 | 2.115975% |
| C | 6191 | 86 | 1.389113% |
| D | 6191 | 209 | 3.375868% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7195 | 6191 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7196 | 6192 | 46 | 46 | 0.64% | 0.74% |  |
| C | 7196 | 6193 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7196 | 6192 | 143 | 143 | 1.99% | 2.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10698 | 64.31 | 768 | 752 | 154.7 |
| A | 3 | 137 | 7654 | 44.63 | 768 | 752 | 154.7 |
| A | 0 | 226 | 6554 | 37.51 | 768 | 752 | 154.7 |
| B | 10 | 245 | 226536 | 1527.76 | 758 | 739 | 147.8 |
| B | 4 | 200 | 53959 | 360.09 | 758 | 739 | 147.8 |
| B | 0 | 183 | 25807 | 169.61 | 758 | 739 | 147.8 |
| C | 14 | 238 | 116230 | 677.71 | 723 | 727 | 170.4 |
| C | 0 | 10 | 19958 | 112.84 | 723 | 727 | 170.4 |
| C | 3 | 233 | 18211 | 102.59 | 723 | 727 | 170.4 |
| D | 1 | 52 | 1196301 | 6953.76 | 721 | 704 | 171.9 |
| D | 8 | 195 | 385777 | 2239.64 | 721 | 704 | 171.9 |
| D | 7 | 238 | 80636 | 464.9 | 721 | 704 | 171.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
