| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T09_9000004100_28525cztM0_level2.evt | modeM0/AS1A10_058T09_9000004100_28525cztM0_level2_quad_clean.evt |
| Size (bytes) | 593,971,200 | 87,500,160 |
| Size | 566.5 MB | 83.4 MB |
| Events in quadrant A | 4,760,063 | 553,627 |
| Events in quadrant B | 3,992,983 | 558,536 |
| Events in quadrant C | 3,400,389 | 539,088 |
| Events in quadrant D | 5,373,314 | 523,390 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18621 | 2 |
| B | 0 | 16103 | 2 |
| C | 0 | 14372 | 2 |
| D | 0 | 20452 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6824 | 466 | 6.828839% |
| B | 6825 | 226 | 3.311355% |
| C | 6825 | 128 | 1.875458% |
| D | 6825 | 297 | 4.351648% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7754 | 6824 | 243 | 243 | 3.13% | 3.56% |  |
| B | 7755 | 6825 | 94 | 94 | 1.21% | 1.38% |  |
| C | 7755 | 6825 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7755 | 6825 | 180 | 180 | 2.32% | 2.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 1464496 | 8483.47 | 853 | 836 | 172.5 |
| A | 13 | 254 | 12694 | 68.73 | 853 | 836 | 172.5 |
| A | 3 | 137 | 8116 | 42.19 | 853 | 836 | 172.5 |
| B | 10 | 245 | 519424 | 3148.69 | 852 | 832 | 164.7 |
| B | 5 | 172 | 37598 | 223.23 | 852 | 832 | 164.7 |
| B | 4 | 171 | 28061 | 165.32 | 852 | 832 | 164.7 |
| C | 14 | 238 | 135202 | 698.36 | 824 | 829 | 192.4 |
| C | 3 | 233 | 36889 | 187.41 | 824 | 829 | 192.4 |
| C | 7 | 247 | 20356 | 101.48 | 824 | 829 | 192.4 |
| D | 1 | 52 | 1117221 | 5601.8 | 828 | 806 | 199.3 |
| D | 8 | 195 | 892961 | 4476.53 | 828 | 806 | 199.3 |
| D | 2 | 250 | 81885 | 406.83 | 828 | 806 | 199.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
