| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_102T07_9000004102_28561cztM0_level2.evt | modeM0/AS1A10_102T07_9000004102_28561cztM0_level2_quad_clean.evt |
| Size (bytes) | 538,087,680 | 96,552,000 |
| Size | 513.2 MB | 92.1 MB |
| Events in quadrant A | 3,514,070 | 641,626 |
| Events in quadrant B | 3,416,102 | 640,732 |
| Events in quadrant C | 3,436,770 | 599,778 |
| Events in quadrant D | 5,475,352 | 575,152 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14669 | 2 |
| B | 0 | 14268 | 2 |
| C | 0 | 14361 | 2 |
| D | 0 | 20773 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6693 | 83 | 1.240102% |
| B | 6693 | 93 | 1.389511% |
| C | 6693 | 109 | 1.628567% |
| D | 6693 | 419 | 6.260272% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7758 | 6693 | 10 | 10 | 0.13% | 0.15% |  |
| B | 7758 | 6693 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7758 | 6693 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7758 | 6693 | 573 | 573 | 7.39% | 8.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 165482 | 951.39 | 866 | 853 | 173.0 |
| A | 8 | 192 | 12229 | 65.74 | 866 | 853 | 173.0 |
| A | 13 | 254 | 11549 | 61.81 | 866 | 853 | 173.0 |
| B | 4 | 171 | 26901 | 160.49 | 855 | 836 | 162.4 |
| B | 15 | 33 | 20185 | 119.14 | 855 | 836 | 162.4 |
| B | 12 | 111 | 20166 | 119.02 | 855 | 836 | 162.4 |
| C | 7 | 247 | 132164 | 690.41 | 812 | 819 | 190.2 |
| C | 14 | 238 | 131758 | 688.27 | 812 | 819 | 190.2 |
| C | 3 | 233 | 8482 | 40.28 | 812 | 819 | 190.2 |
| D | 8 | 195 | 1215458 | 6179.93 | 817 | 797 | 196.5 |
| D | 1 | 52 | 759802 | 3861.65 | 817 | 797 | 196.5 |
| D | 2 | 250 | 258553 | 1311.41 | 817 | 797 | 196.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
