| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_102T03_9000004106_28577cztM0_level2.evt | modeM0/AS1A10_102T03_9000004106_28577cztM0_level2_quad_clean.evt |
| Size (bytes) | 652,870,080 | 92,197,440 |
| Size | 622.6 MB | 87.9 MB |
| Events in quadrant A | 5,638,972 | 528,374 |
| Events in quadrant B | 3,818,691 | 603,110 |
| Events in quadrant C | 3,731,198 | 583,064 |
| Events in quadrant D | 6,087,100 | 567,445 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21512 | 2 |
| B | 0 | 16063 | 2 |
| C | 0 | 15669 | 2 |
| D | 0 | 23225 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7319 | 921 | 12.583686% |
| B | 7319 | 136 | 1.858177% |
| C | 7319 | 162 | 2.213417% |
| D | 7319 | 603 | 8.238830% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8734 | 7321 | 832 | 832 | 9.53% | 11.36% |  |
| B | 8734 | 7321 | 17 | 17 | 0.19% | 0.23% |  |
| C | 8734 | 7320 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8734 | 7320 | 398 | 398 | 4.56% | 5.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 2329515 | 13589.87 | 846 | 827 | 171.4 |
| A | 8 | 192 | 14403 | 79.23 | 846 | 827 | 171.4 |
| A | 12 | 96 | 12702 | 69.3 | 846 | 827 | 171.4 |
| B | 4 | 171 | 77479 | 435.65 | 913 | 892 | 175.8 |
| B | 4 | 80 | 65809 | 369.27 | 913 | 892 | 175.8 |
| B | 0 | 230 | 45653 | 254.61 | 913 | 892 | 175.8 |
| C | 14 | 238 | 142980 | 686.39 | 884 | 890 | 207.0 |
| C | 0 | 207 | 52251 | 248.11 | 884 | 890 | 207.0 |
| C | 7 | 247 | 41570 | 196.51 | 884 | 890 | 207.0 |
| D | 1 | 52 | 2157915 | 10258.0 | 867 | 844 | 210.3 |
| D | 8 | 195 | 493508 | 2342.87 | 867 | 844 | 210.3 |
| D | 2 | 250 | 74632 | 350.9 | 867 | 844 | 210.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
