| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_045T06_9000004108_28605cztM0_level2.evt | modeM0/AS1A10_045T06_9000004108_28605cztM0_level2_quad_clean.evt |
| Size (bytes) | 544,826,880 | 72,288,000 |
| Size | 519.6 MB | 68.9 MB |
| Events in quadrant A | 4,015,042 | 431,989 |
| Events in quadrant B | 3,573,690 | 434,000 |
| Events in quadrant C | 3,581,583 | 425,696 |
| Events in quadrant D | 4,862,584 | 417,020 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16128 | 3 |
| B | 0 | 14672 | 2 |
| C | 0 | 14618 | 2 |
| D | 0 | 19123 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6890 | 285 | 4.136430% |
| B | 6890 | 90 | 1.306241% |
| C | 6890 | 145 | 2.104499% |
| D | 6890 | 227 | 3.294630% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7750 | 6890 | 150 | 150 | 1.94% | 2.18% |  |
| B | 7750 | 6890 | 5 | 5 | 0.06% | 0.07% |  |
| C | 7750 | 6890 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7750 | 6890 | 132 | 132 | 1.70% | 1.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 540950 | 3031.16 | 886 | 868 | 178.2 |
| A | 15 | 47 | 44178 | 243.07 | 886 | 868 | 178.2 |
| A | 13 | 254 | 12284 | 64.07 | 886 | 868 | 178.2 |
| B | 10 | 245 | 70022 | 410.28 | 885 | 862 | 168.6 |
| B | 12 | 111 | 20416 | 116.0 | 885 | 862 | 168.6 |
| B | 10 | 247 | 19982 | 113.43 | 885 | 862 | 168.6 |
| C | 14 | 238 | 138787 | 673.93 | 864 | 871 | 204.6 |
| C | 7 | 247 | 28562 | 135.31 | 864 | 871 | 204.6 |
| C | 3 | 233 | 19669 | 91.86 | 864 | 871 | 204.6 |
| D | 1 | 52 | 740825 | 3552.54 | 871 | 848 | 208.3 |
| D | 8 | 195 | 690912 | 3312.91 | 871 | 848 | 208.3 |
| D | 2 | 250 | 47822 | 225.52 | 871 | 848 | 208.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
