| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_045T06_9000004108_28622cztM0_level2.evt | modeM0/AS1A10_045T06_9000004108_28622cztM0_level2_quad_clean.evt |
| Size (bytes) | 657,120,960 | 87,085,440 |
| Size | 626.7 MB | 83.1 MB |
| Events in quadrant A | 3,820,939 | 535,672 |
| Events in quadrant B | 4,065,739 | 538,705 |
| Events in quadrant C | 3,932,321 | 526,837 |
| Events in quadrant D | 7,556,075 | 495,729 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16363 | 2 |
| B | 0 | 17001 | 2 |
| C | 0 | 16648 | 2 |
| D | 0 | 27923 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7770 | 103 | 1.325611% |
| B | 7771 | 161 | 2.071805% |
| C | 7770 | 274 | 3.526384% |
| D | 7770 | 939 | 12.084942% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8325 | 7771 | 4 | 4 | 0.05% | 0.05% |  |
| B | 8326 | 7772 | 21 | 21 | 0.25% | 0.27% |  |
| C | 8325 | 7771 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8325 | 7772 | 587 | 587 | 7.05% | 7.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 39130 | 192.96 | 973 | 951 | 197.9 |
| A | 8 | 192 | 13861 | 65.25 | 973 | 951 | 197.9 |
| A | 13 | 254 | 13409 | 62.96 | 973 | 951 | 197.9 |
| B | 10 | 246 | 211177 | 1136.68 | 962 | 937 | 185.0 |
| B | 12 | 111 | 22839 | 118.42 | 962 | 937 | 185.0 |
| B | 11 | 111 | 20840 | 107.61 | 962 | 937 | 185.0 |
| C | 14 | 238 | 176345 | 799.41 | 930 | 935 | 219.4 |
| C | 3 | 233 | 50660 | 226.61 | 930 | 935 | 219.4 |
| C | 14 | 254 | 38319 | 170.37 | 930 | 935 | 219.4 |
| D | 1 | 52 | 3118193 | 14435.91 | 908 | 884 | 215.9 |
| D | 8 | 195 | 736183 | 3405.09 | 908 | 884 | 215.9 |
| D | 2 | 250 | 134291 | 617.79 | 908 | 884 | 215.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
