| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_110T03_9000004114_28676cztM0_level2.evt | modeM0/AS1A10_110T03_9000004114_28676cztM0_level2_quad_clean.evt |
| Size (bytes) | 584,081,280 | 72,803,520 |
| Size | 557.0 MB | 69.4 MB |
| Events in quadrant A | 3,602,763 | 445,898 |
| Events in quadrant B | 3,955,230 | 450,621 |
| Events in quadrant C | 3,736,077 | 432,278 |
| Events in quadrant D | 5,946,258 | 413,536 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14593 | 2 |
| B | 0 | 15739 | 2 |
| C | 0 | 15060 | 2 |
| D | 0 | 22447 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6626 | 103 | 1.554482% |
| B | 6626 | 166 | 2.505282% |
| C | 6626 | 168 | 2.535466% |
| D | 6626 | 595 | 8.979777% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7876 | 6626 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7876 | 6626 | 26 | 26 | 0.33% | 0.39% |  |
| C | 7876 | 6626 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7876 | 6626 | 456 | 456 | 5.79% | 6.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11384 | 56.37 | 932 | 915 | 185.7 |
| A | 3 | 137 | 8164 | 39.03 | 932 | 915 | 185.7 |
| A | 15 | 174 | 8088 | 38.62 | 932 | 915 | 185.7 |
| B | 15 | 33 | 240977 | 1409.13 | 910 | 889 | 170.4 |
| B | 10 | 245 | 123192 | 717.82 | 910 | 889 | 170.4 |
| B | 0 | 190 | 26717 | 151.59 | 910 | 889 | 170.4 |
| C | 14 | 238 | 151399 | 730.83 | 893 | 900 | 205.9 |
| C | 3 | 233 | 56755 | 271.23 | 893 | 900 | 205.9 |
| C | 2 | 16 | 23242 | 108.49 | 893 | 900 | 205.9 |
| D | 1 | 52 | 1788196 | 8561.84 | 882 | 864 | 208.8 |
| D | 8 | 195 | 483105 | 2310.07 | 882 | 864 | 208.8 |
| D | 2 | 250 | 227149 | 1083.97 | 882 | 864 | 208.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
