| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T07_9000004124_28732cztM0_level2.evt | modeM0/AS1A10_123T07_9000004124_28732cztM0_level2_quad_clean.evt |
| Size (bytes) | 462,729,600 | 94,227,840 |
| Size | 441.3 MB | 89.9 MB |
| Events in quadrant A | 3,083,709 | 630,540 |
| Events in quadrant B | 3,032,890 | 634,896 |
| Events in quadrant C | 3,062,833 | 598,276 |
| Events in quadrant D | 4,441,267 | 585,081 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12419 | 1 |
| B | 0 | 12263 | 1 |
| C | 0 | 12359 | 1 |
| D | 0 | 17303 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5798 | 37 | 0.638151% |
| B | 5799 | 42 | 0.724263% |
| C | 5799 | 113 | 1.948612% |
| D | 5799 | 225 | 3.879979% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7148 | 5798 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7149 | 5799 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7149 | 5800 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7149 | 5799 | 118 | 118 | 1.65% | 2.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 27815 | 172.63 | 790 | 775 | 156.6 |
| A | 13 | 254 | 11093 | 65.87 | 790 | 775 | 156.6 |
| A | 0 | 226 | 6865 | 38.88 | 790 | 775 | 156.6 |
| B | 12 | 111 | 16805 | 112.69 | 767 | 751 | 142.5 |
| B | 11 | 111 | 15029 | 100.22 | 767 | 751 | 142.5 |
| B | 14 | 111 | 13972 | 92.8 | 767 | 751 | 142.5 |
| C | 14 | 238 | 150276 | 892.75 | 733 | 739 | 167.5 |
| C | 14 | 254 | 39220 | 229.74 | 733 | 739 | 167.5 |
| C | 3 | 233 | 15963 | 90.89 | 733 | 739 | 167.5 |
| D | 1 | 52 | 1048480 | 6048.73 | 743 | 725 | 173.2 |
| D | 8 | 195 | 507770 | 2927.19 | 743 | 725 | 173.2 |
| D | 7 | 69 | 56285 | 320.75 | 743 | 725 | 173.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
