| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_093T01_9000004128_28762cztM0_level2.evt | modeM0/AS1A10_093T01_9000004128_28762cztM0_level2_quad_clean.evt |
| Size (bytes) | 616,368,960 | 69,359,040 |
| Size | 587.8 MB | 66.1 MB |
| Events in quadrant A | 3,472,877 | 446,938 |
| Events in quadrant B | 4,073,907 | 449,789 |
| Events in quadrant C | 4,998,626 | 400,584 |
| Events in quadrant D | 5,697,236 | 364,349 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13991 | 2 |
| B | 0 | 16097 | 2 |
| C | 0 | 19260 | 3 |
| D | 0 | 21188 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6283 | 65 | 1.034538% |
| B | 6283 | 188 | 2.992201% |
| C | 6282 | 295 | 4.695957% |
| D | 6282 | 641 | 10.203757% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7663 | 6283 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7663 | 6283 | 64 | 64 | 0.84% | 1.02% |  |
| C | 7662 | 6282 | 37 | 37 | 0.48% | 0.59% |  |
| D | 7662 | 6282 | 551 | 551 | 7.19% | 8.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 239 | 12055 | 63.52 | 896 | 882 | 175.9 |
| A | 13 | 254 | 10584 | 55.16 | 896 | 882 | 175.9 |
| A | 0 | 226 | 7653 | 38.5 | 896 | 882 | 175.9 |
| B | 4 | 80 | 309739 | 1871.48 | 887 | 870 | 165.0 |
| B | 5 | 255 | 234035 | 1412.78 | 887 | 870 | 165.0 |
| B | 12 | 111 | 18648 | 107.72 | 887 | 870 | 165.0 |
| C | 3 | 233 | 1553242 | 8237.15 | 827 | 836 | 188.5 |
| C | 14 | 238 | 155358 | 819.9 | 827 | 836 | 188.5 |
| C | 4 | 254 | 28530 | 146.95 | 827 | 836 | 188.5 |
| D | 1 | 52 | 1481448 | 7862.79 | 806 | 787 | 188.3 |
| D | 8 | 195 | 932159 | 4945.89 | 806 | 787 | 188.3 |
| D | 12 | 233 | 180425 | 953.94 | 806 | 787 | 188.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
