| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_103T01_9000004132_28788cztM0_level2.evt | modeM0/AS1A10_103T01_9000004132_28788cztM0_level2_quad_clean.evt |
| Size (bytes) | 695,782,080 | 107,611,200 |
| Size | 663.5 MB | 102.6 MB |
| Events in quadrant A | 3,385,675 | 720,660 |
| Events in quadrant B | 3,454,938 | 749,946 |
| Events in quadrant C | 3,811,670 | 709,854 |
| Events in quadrant D | 9,963,178 | 607,639 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14388 | 2 |
| B | 0 | 14485 | 2 |
| C | 0 | 15673 | 2 |
| D | 0 | 34379 | 6 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6749 | 25 | 0.370425% |
| B | 6749 | 44 | 0.651948% |
| C | 6749 | 151 | 2.237368% |
| D | 6748 | 1781 | 26.393005% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7914 | 6749 | 5 | 5 | 0.06% | 0.07% |  |
| B | 7914 | 6749 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7914 | 6749 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7913 | 6748 | 1808 | 1808 | 22.85% | 26.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 121621 | 715.98 | 844 | 826 | 168.7 |
| A | 13 | 254 | 12595 | 69.76 | 844 | 826 | 168.7 |
| A | 3 | 137 | 7756 | 41.08 | 844 | 826 | 168.7 |
| B | 10 | 246 | 46436 | 286.18 | 853 | 832 | 159.4 |
| B | 10 | 245 | 20911 | 126.0 | 853 | 832 | 159.4 |
| B | 12 | 111 | 19354 | 116.23 | 853 | 832 | 159.4 |
| C | 3 | 233 | 405773 | 2105.94 | 825 | 832 | 192.3 |
| C | 14 | 238 | 153230 | 792.56 | 825 | 832 | 192.3 |
| C | 14 | 254 | 29668 | 149.97 | 825 | 832 | 192.3 |
| D | 1 | 52 | 4462905 | 25932.1 | 729 | 710 | 172.1 |
| D | 8 | 195 | 1722701 | 10007.37 | 729 | 710 | 172.1 |
| D | 13 | 104 | 942512 | 5473.29 | 729 | 710 | 172.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
