| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_121T01_9000004134_28808cztM0_level2.evt | modeM0/AS1A10_121T01_9000004134_28808cztM0_level2_quad_clean.evt |
| Size (bytes) | 596,871,360 | 99,673,920 |
| Size | 569.2 MB | 95.1 MB |
| Events in quadrant A | 3,318,488 | 664,573 |
| Events in quadrant B | 3,659,658 | 678,789 |
| Events in quadrant C | 3,472,303 | 651,640 |
| Events in quadrant D | 7,201,549 | 585,860 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13696 | 1 |
| B | 0 | 14715 | 1 |
| C | 0 | 14053 | 1 |
| D | 0 | 25789 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6264 | 109 | 1.740102% |
| B | 6264 | 276 | 4.406130% |
| C | 6264 | 196 | 3.128991% |
| D | 6264 | 1062 | 16.954023% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6979 | 6264 | 21 | 21 | 0.30% | 0.34% |  |
| B | 6979 | 6264 | 146 | 146 | 2.09% | 2.33% |  |
| C | 6979 | 6264 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6978 | 6263 | 974 | 974 | 13.96% | 15.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 266508 | 1748.68 | 763 | 747 | 152.0 |
| A | 4 | 2 | 45515 | 294.57 | 763 | 747 | 152.0 |
| A | 14 | 239 | 24059 | 153.39 | 763 | 747 | 152.0 |
| B | 5 | 172 | 570484 | 4049.88 | 753 | 734 | 140.7 |
| B | 5 | 255 | 78947 | 555.95 | 753 | 734 | 140.7 |
| B | 0 | 190 | 18041 | 123.02 | 753 | 734 | 140.7 |
| C | 3 | 233 | 395012 | 2277.24 | 738 | 742 | 173.1 |
| C | 14 | 238 | 143969 | 827.26 | 738 | 742 | 173.1 |
| C | 14 | 254 | 37301 | 211.16 | 738 | 742 | 173.1 |
| D | 1 | 52 | 2955844 | 17473.13 | 706 | 687 | 169.1 |
| D | 8 | 195 | 994698 | 5877.35 | 706 | 687 | 169.1 |
| D | 12 | 233 | 348041 | 2053.82 | 706 | 687 | 169.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
