| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_121T01_9000004134_28818cztM0_level2.evt | modeM0/AS1A10_121T01_9000004134_28818cztM0_level2_quad_clean.evt |
| Size (bytes) | 612,023,040 | 105,592,320 |
| Size | 583.7 MB | 100.7 MB |
| Events in quadrant A | 3,029,644 | 711,263 |
| Events in quadrant B | 3,141,242 | 745,256 |
| Events in quadrant C | 3,853,212 | 702,965 |
| Events in quadrant D | 8,103,331 | 616,878 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12717 | 1 |
| B | 0 | 13009 | 1 |
| C | 0 | 15825 | 1 |
| D | 0 | 28379 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6035 | 9 | 0.149130% |
| B | 6035 | 38 | 0.629660% |
| C | 6035 | 182 | 3.015742% |
| D | 6035 | 964 | 15.973488% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7300 | 6036 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7300 | 6035 | 13 | 13 | 0.18% | 0.22% |  |
| C | 7300 | 6035 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7300 | 6035 | 1046 | 1046 | 14.33% | 17.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 23794 | 149.42 | 769 | 755 | 154.2 |
| A | 14 | 239 | 12676 | 77.31 | 769 | 755 | 154.2 |
| A | 13 | 254 | 12276 | 74.72 | 769 | 755 | 154.2 |
| B | 5 | 172 | 67868 | 464.22 | 778 | 761 | 144.6 |
| B | 12 | 111 | 16312 | 107.58 | 778 | 761 | 144.6 |
| B | 11 | 111 | 14656 | 96.12 | 778 | 761 | 144.6 |
| C | 3 | 233 | 667802 | 3830.4 | 755 | 760 | 174.1 |
| C | 14 | 238 | 155901 | 890.88 | 755 | 760 | 174.1 |
| C | 14 | 254 | 50202 | 283.91 | 755 | 760 | 174.1 |
| D | 8 | 195 | 3967740 | 23110.21 | 719 | 699 | 171.7 |
| D | 1 | 52 | 736910 | 4288.84 | 719 | 699 | 171.7 |
| D | 12 | 233 | 252437 | 1466.51 | 719 | 699 | 171.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
