| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_121T01_9000004134_28839cztM0_level2.evt | modeM0/AS1A10_121T01_9000004134_28839cztM0_level2_quad_clean.evt |
| Size (bytes) | 812,554,560 | 102,994,560 |
| Size | 774.9 MB | 98.2 MB |
| Events in quadrant A | 3,532,602 | 679,259 |
| Events in quadrant B | 4,475,364 | 687,301 |
| Events in quadrant C | 8,077,654 | 630,166 |
| Events in quadrant D | 8,027,966 | 611,019 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15341 | 1 |
| B | 0 | 17941 | 1 |
| C | 0 | 29265 | 1 |
| D | 0 | 28804 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7335 | 216 | 2.944785% |
| B | 7336 | 500 | 6.815703% |
| C | 7336 | 1116 | 15.212650% |
| D | 7336 | 1115 | 15.199019% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7435 | 7335 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7436 | 7336 | 184 | 184 | 2.47% | 2.51% |  |
| C | 7435 | 7335 | 260 | 260 | 3.50% | 3.54% |  |
| D | 7435 | 7335 | 849 | 849 | 11.42% | 11.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 77954 | 424.91 | 893 | 872 | 181.4 |
| A | 13 | 254 | 14095 | 72.89 | 893 | 872 | 181.4 |
| A | 3 | 137 | 8613 | 42.67 | 893 | 872 | 181.4 |
| B | 5 | 172 | 506866 | 3056.3 | 875 | 854 | 165.6 |
| B | 10 | 245 | 325607 | 1961.5 | 875 | 854 | 165.6 |
| B | 0 | 244 | 74002 | 441.81 | 875 | 854 | 165.6 |
| C | 3 | 233 | 4510199 | 23264.83 | 832 | 837 | 193.8 |
| C | 14 | 238 | 193229 | 992.59 | 832 | 837 | 193.8 |
| C | 14 | 254 | 93533 | 478.24 | 832 | 837 | 193.8 |
| D | 8 | 195 | 2795032 | 13959.35 | 840 | 817 | 200.2 |
| D | 13 | 104 | 780468 | 3894.98 | 840 | 817 | 200.2 |
| D | 1 | 52 | 632172 | 3154.13 | 840 | 817 | 200.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
