| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_103T08_9000004136_28844cztM0_level2.evt | modeM0/AS1A10_103T08_9000004136_28844cztM0_level2_quad_clean.evt |
| Size (bytes) | 680,374,080 | 121,291,200 |
| Size | 648.9 MB | 115.7 MB |
| Events in quadrant A | 3,015,918 | 857,011 |
| Events in quadrant B | 3,707,364 | 859,067 |
| Events in quadrant C | 3,134,799 | 823,566 |
| Events in quadrant D | 10,313,625 | 685,538 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13175 | 2 |
| B | 0 | 15184 | 1 |
| C | 0 | 13264 | 1 |
| D | 0 | 35094 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6411 | 12 | 0.187178% |
| B | 6412 | 206 | 3.212726% |
| C | 6412 | 66 | 1.029320% |
| D | 6412 | 1614 | 25.171553% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7456 | 6411 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7457 | 6412 | 95 | 95 | 1.27% | 1.48% |  |
| C | 7457 | 6413 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7457 | 6412 | 1745 | 1745 | 23.40% | 27.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 192 | 15877 | 97.6 | 771 | 754 | 154.9 |
| A | 13 | 254 | 13224 | 80.48 | 771 | 754 | 154.9 |
| A | 14 | 235 | 13221 | 80.46 | 771 | 754 | 154.9 |
| B | 5 | 172 | 324089 | 2239.99 | 766 | 747 | 144.3 |
| B | 5 | 255 | 101707 | 699.41 | 766 | 747 | 144.3 |
| B | 10 | 245 | 91554 | 629.08 | 766 | 747 | 144.3 |
| C | 3 | 233 | 126509 | 731.52 | 736 | 740 | 171.9 |
| C | 14 | 238 | 126294 | 730.27 | 736 | 740 | 171.9 |
| C | 14 | 254 | 10358 | 55.94 | 736 | 740 | 171.9 |
| D | 8 | 195 | 4398035 | 27379.6 | 668 | 650 | 160.6 |
| D | 1 | 52 | 1717763 | 10691.32 | 668 | 650 | 160.6 |
| D | 13 | 104 | 1358156 | 8452.29 | 668 | 650 | 160.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
