| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T06_9000004138_28862cztM0_level2.evt | modeM0/AS1A10_123T06_9000004138_28862cztM0_level2_quad_clean.evt |
| Size (bytes) | 268,139,520 | 57,340,800 |
| Size | 255.7 MB | 54.7 MB |
| Events in quadrant A | 1,316,840 | 407,379 |
| Events in quadrant B | 1,467,573 | 427,410 |
| Events in quadrant C | 1,362,849 | 395,568 |
| Events in quadrant D | 3,804,729 | 328,808 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8667 | 3234 |
| B | 0 | 8514 | 2597 |
| C | 0 | 8305 | 2698 |
| D | 0 | 18468 | 5525 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 77 | 23 |
| B | 0 | 75 | 27 |
| C | 0 | 78 | 28 |
| D | 0 | 77 | 27 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 3 |
| B | 0 | 19 | 4 |
| C | 0 | 19 | 2 |
| D | 0 | 19 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2460 | 4 | 0.162602% |
| B | 2501 | 41 | 1.639344% |
| C | 2455 | 32 | 1.303462% |
| D | 2386 | 957 | 40.108969% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7809 | 2625 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7809 | 2659 | 12 | 12 | 0.15% | 0.45% |  |
| C | 7808 | 2611 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7807 | 2517 | 1140 | 1140 | 14.60% | 45.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 32771 | 493.07 | 332 | 326 | 65.8 |
| A | 13 | 254 | 4723 | 66.82 | 332 | 326 | 65.8 |
| A | 1 | 113 | 3391 | 46.58 | 332 | 326 | 65.8 |
| B | 5 | 255 | 118144 | 1834.38 | 342 | 336 | 64.2 |
| B | 15 | 33 | 13430 | 203.89 | 342 | 336 | 64.2 |
| B | 12 | 111 | 7192 | 106.75 | 342 | 336 | 64.2 |
| C | 14 | 238 | 56751 | 748.62 | 323 | 324 | 75.4 |
| C | 4 | 254 | 19578 | 255.44 | 323 | 324 | 75.4 |
| C | 3 | 233 | 14044 | 182.02 | 323 | 324 | 75.4 |
| D | 8 | 195 | 2224375 | 32038.7 | 287 | 278 | 69.4 |
| D | 1 | 52 | 299307 | 4307.59 | 287 | 278 | 69.4 |
| D | 7 | 80 | 174457 | 2509.09 | 287 | 278 | 69.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
