| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T06_9000004138_28871cztM0_level2.evt | modeM0/AS1A10_123T06_9000004138_28871cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,289,448,000 | 191,540,160 |
| Size | 1.2 GB | 182.7 MB |
| Events in quadrant A | 7,387,244 | 1,225,179 |
| Events in quadrant B | 8,716,327 | 1,207,942 |
| Events in quadrant C | 7,226,341 | 1,198,762 |
| Events in quadrant D | 14,702,639 | 1,127,371 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31784 | 3 |
| B | 0 | 35803 | 3 |
| C | 0 | 31115 | 3 |
| D | 0 | 53790 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 304 | 0 |
| B | 0 | 304 | 0 |
| C | 0 | 304 | 0 |
| D | 0 | 304 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15094 | 176 | 1.166026% |
| B | 15095 | 803 | 5.319642% |
| C | 15095 | 286 | 1.894667% |
| D | 15095 | 1884 | 12.480954% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 16064 | 15094 | 9 | 9 | 0.06% | 0.06% |  |
| B | 16065 | 15095 | 666 | 666 | 4.15% | 4.41% |  |
| C | 16065 | 15095 | 0 | 0 | 0.00% | 0.00% |  |
| D | 16065 | 15095 | 1987 | 1987 | 12.37% | 13.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 319431 | 872.75 | 1805 | 1762 | 364.0 |
| A | 1 | 113 | 84978 | 228.62 | 1805 | 1762 | 364.0 |
| A | 13 | 254 | 28903 | 74.57 | 1805 | 1762 | 364.0 |
| B | 10 | 245 | 1802835 | 5529.05 | 1714 | 1671 | 325.8 |
| B | 5 | 255 | 68258 | 204.4 | 1714 | 1671 | 325.8 |
| B | 15 | 32 | 55561 | 165.43 | 1714 | 1671 | 325.8 |
| C | 14 | 238 | 296428 | 732.94 | 1725 | 1732 | 402.1 |
| C | 3 | 233 | 118450 | 290.29 | 1725 | 1732 | 402.1 |
| C | 14 | 254 | 32351 | 76.15 | 1725 | 1732 | 402.1 |
| D | 8 | 195 | 6709249 | 16522.47 | 1690 | 1640 | 406.0 |
| D | 7 | 80 | 1121625 | 2758.79 | 1690 | 1640 | 406.0 |
| D | 1 | 52 | 139545 | 339.69 | 1690 | 1640 | 406.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
