| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_082T04_9000004150_28941cztM0_level2.evt | modeM0/AS1A10_082T04_9000004150_28941cztM0_level2_quad_clean.evt |
| Size (bytes) | 653,137,920 | 93,968,640 |
| Size | 622.9 MB | 89.6 MB |
| Events in quadrant A | 3,287,609 | 609,371 |
| Events in quadrant B | 3,363,487 | 625,784 |
| Events in quadrant C | 3,383,186 | 599,136 |
| Events in quadrant D | 9,260,983 | 512,338 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14512 | 1 |
| B | 0 | 14657 | 1 |
| C | 0 | 14690 | 2 |
| D | 0 | 32475 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7153 | 74 | 1.034531% |
| B | 7154 | 94 | 1.313950% |
| C | 7153 | 189 | 2.642248% |
| D | 7153 | 2048 | 28.631343% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7475 | 7156 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7476 | 7157 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7475 | 7156 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7475 | 7156 | 1943 | 1943 | 25.99% | 27.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11278 | 60.95 | 850 | 830 | 171.4 |
| A | 3 | 137 | 8602 | 45.34 | 850 | 830 | 171.4 |
| A | 0 | 226 | 7116 | 36.67 | 850 | 830 | 171.4 |
| B | 10 | 245 | 27263 | 161.89 | 843 | 818 | 163.4 |
| B | 12 | 111 | 20498 | 120.48 | 843 | 818 | 163.4 |
| B | 11 | 111 | 18568 | 108.66 | 843 | 818 | 163.4 |
| C | 14 | 238 | 163481 | 851.93 | 809 | 812 | 190.9 |
| C | 14 | 254 | 45344 | 233.22 | 809 | 812 | 190.9 |
| C | 2 | 114 | 16778 | 83.62 | 809 | 812 | 190.9 |
| D | 8 | 195 | 3659892 | 20875.36 | 731 | 711 | 175.3 |
| D | 1 | 52 | 2823565 | 16104.17 | 731 | 711 | 175.3 |
| D | 2 | 234 | 27819 | 154.65 | 731 | 711 | 175.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
