| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_048T03_9000004154_28977cztM0_level2.evt | modeM0/AS1A10_048T03_9000004154_28977cztM0_level2_quad_clean.evt |
| Size (bytes) | 554,051,520 | 96,580,800 |
| Size | 528.4 MB | 92.1 MB |
| Events in quadrant A | 3,349,278 | 640,014 |
| Events in quadrant B | 3,459,485 | 659,140 |
| Events in quadrant C | 3,396,366 | 620,147 |
| Events in quadrant D | 6,147,396 | 565,689 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14048 | 2 |
| B | 0 | 14387 | 2 |
| C | 0 | 14112 | 2 |
| D | 0 | 22591 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6302 | 61 | 0.967947% |
| B | 6302 | 91 | 1.443986% |
| C | 6302 | 114 | 1.808950% |
| D | 6302 | 748 | 11.869248% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7547 | 6303 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7547 | 6303 | 16 | 16 | 0.21% | 0.25% |  |
| C | 7547 | 6303 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7547 | 6303 | 657 | 657 | 8.71% | 10.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 210 | 36962 | 211.77 | 850 | 837 | 170.6 |
| A | 8 | 34 | 14136 | 77.96 | 850 | 837 | 170.6 |
| A | 13 | 254 | 12171 | 66.44 | 850 | 837 | 170.6 |
| B | 10 | 245 | 113193 | 697.43 | 850 | 831 | 161.1 |
| B | 12 | 111 | 19032 | 112.97 | 850 | 831 | 161.1 |
| B | 11 | 111 | 17266 | 102.01 | 850 | 831 | 161.1 |
| C | 14 | 238 | 133078 | 694.12 | 814 | 822 | 190.5 |
| C | 3 | 233 | 63783 | 330.44 | 814 | 822 | 190.5 |
| C | 2 | 114 | 15462 | 76.84 | 814 | 822 | 190.5 |
| D | 1 | 52 | 1341744 | 7264.03 | 780 | 761 | 184.6 |
| D | 7 | 80 | 909170 | 4920.8 | 780 | 761 | 184.6 |
| D | 8 | 195 | 831414 | 4499.6 | 780 | 761 | 184.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
