| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_073T06_9000004156_28996cztM0_level2.evt | modeM0/AS1A10_073T06_9000004156_28996cztM0_level2_quad_clean.evt |
| Size (bytes) | 484,018,560 | 90,230,400 |
| Size | 461.6 MB | 86.1 MB |
| Events in quadrant A | 3,235,010 | 575,526 |
| Events in quadrant B | 3,477,531 | 590,837 |
| Events in quadrant C | 3,328,699 | 556,210 |
| Events in quadrant D | 4,149,849 | 530,232 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14108 | 2 |
| B | 0 | 14710 | 2 |
| C | 0 | 14194 | 2 |
| D | 0 | 17025 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6883 | 23 | 0.334157% |
| B | 6882 | 97 | 1.409474% |
| C | 6882 | 56 | 0.813717% |
| D | 6882 | 128 | 1.859924% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7713 | 6879 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7712 | 6878 | 42 | 42 | 0.54% | 0.61% |  |
| C | 7712 | 6878 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7712 | 6878 | 110 | 110 | 1.43% | 1.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12185 | 67.62 | 835 | 818 | 168.1 |
| A | 3 | 137 | 8134 | 43.52 | 835 | 818 | 168.1 |
| A | 0 | 226 | 6934 | 36.39 | 835 | 818 | 168.1 |
| B | 10 | 246 | 128475 | 803.28 | 833 | 810 | 158.9 |
| B | 10 | 245 | 58001 | 359.85 | 833 | 810 | 158.9 |
| B | 12 | 111 | 19758 | 119.22 | 833 | 810 | 158.9 |
| C | 14 | 238 | 129718 | 682.66 | 805 | 810 | 188.8 |
| C | 3 | 233 | 42529 | 220.93 | 805 | 810 | 188.8 |
| C | 2 | 114 | 16231 | 81.67 | 805 | 810 | 188.8 |
| D | 8 | 195 | 523007 | 2771.68 | 798 | 776 | 188.4 |
| D | 13 | 104 | 419218 | 2220.83 | 798 | 776 | 188.4 |
| D | 1 | 52 | 79783 | 419.32 | 798 | 776 | 188.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
