| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_019T04_9000004162_29046cztM0_level2.evt | modeM0/AS1C05_019T04_9000004162_29046cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,072,640 | 93,974,400 |
| Size | 445.4 MB | 89.6 MB |
| Events in quadrant A | 3,030,383 | 610,465 |
| Events in quadrant B | 3,153,470 | 619,395 |
| Events in quadrant C | 3,058,477 | 595,117 |
| Events in quadrant D | 4,468,336 | 574,392 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13133 | 1 |
| B | 0 | 13479 | 1 |
| C | 0 | 13093 | 1 |
| D | 0 | 17696 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6398 | 51 | 0.797124% |
| B | 6399 | 62 | 0.968901% |
| C | 6399 | 81 | 1.265823% |
| D | 6399 | 224 | 3.500547% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7378 | 6398 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7379 | 6399 | 12 | 12 | 0.16% | 0.19% |  |
| C | 7379 | 6399 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7379 | 6399 | 172 | 172 | 2.33% | 2.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10972 | 65.41 | 778 | 762 | 156.1 |
| A | 6 | 16 | 10848 | 64.62 | 778 | 762 | 156.1 |
| A | 15 | 174 | 9780 | 57.78 | 778 | 762 | 156.1 |
| B | 10 | 245 | 102401 | 700.8 | 765 | 746 | 145.1 |
| B | 12 | 111 | 17935 | 118.5 | 765 | 746 | 145.1 |
| B | 10 | 246 | 17216 | 113.54 | 765 | 746 | 145.1 |
| C | 14 | 238 | 120590 | 688.72 | 743 | 746 | 174.0 |
| C | 2 | 114 | 15016 | 82.01 | 743 | 746 | 174.0 |
| C | 3 | 233 | 12137 | 65.46 | 743 | 746 | 174.0 |
| D | 1 | 52 | 797500 | 4557.11 | 743 | 722 | 174.8 |
| D | 8 | 195 | 663015 | 3787.93 | 743 | 722 | 174.8 |
| D | 2 | 250 | 111347 | 632.71 | 743 | 722 | 174.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
