| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_097T04_9000004170_29068cztM0_level2.evt | modeM0/AS1A10_097T04_9000004170_29068cztM0_level2_quad_clean.evt |
| Size (bytes) | 509,639,040 | 97,084,800 |
| Size | 486.0 MB | 92.6 MB |
| Events in quadrant A | 3,240,078 | 629,428 |
| Events in quadrant B | 3,412,432 | 646,265 |
| Events in quadrant C | 3,366,419 | 609,866 |
| Events in quadrant D | 4,956,323 | 582,657 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14007 | 2 |
| B | 0 | 14436 | 2 |
| C | 0 | 14183 | 2 |
| D | 0 | 19301 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6773 | 23 | 0.339584% |
| B | 6773 | 63 | 0.930164% |
| C | 6773 | 73 | 1.077809% |
| D | 6773 | 276 | 4.075004% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7737 | 6772 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7737 | 6772 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7738 | 6773 | 4 | 4 | 0.05% | 0.06% |  |
| D | 7737 | 6773 | 187 | 187 | 2.42% | 2.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9917 | 53.96 | 839 | 822 | 168.5 |
| A | 3 | 137 | 8241 | 44.02 | 839 | 822 | 168.5 |
| A | 0 | 226 | 6952 | 36.37 | 839 | 822 | 168.5 |
| B | 0 | 183 | 72053 | 445.78 | 840 | 820 | 159.8 |
| B | 12 | 111 | 20215 | 121.37 | 840 | 820 | 159.8 |
| B | 11 | 111 | 18161 | 108.52 | 840 | 820 | 159.8 |
| C | 14 | 238 | 132647 | 687.35 | 812 | 819 | 191.8 |
| C | 2 | 16 | 50246 | 257.71 | 812 | 819 | 191.8 |
| C | 2 | 114 | 15645 | 77.3 | 812 | 819 | 191.8 |
| D | 8 | 195 | 810661 | 4287.89 | 797 | 777 | 188.9 |
| D | 1 | 52 | 790038 | 4178.7 | 797 | 777 | 188.9 |
| D | 7 | 80 | 324559 | 1714.25 | 797 | 777 | 188.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
