| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_099T01_9000004184_29140cztM0_level2.evt | modeM0/AS1A10_099T01_9000004184_29140cztM0_level2_quad_clean.evt |
| Size (bytes) | 490,867,200 | 103,158,720 |
| Size | 468.1 MB | 98.4 MB |
| Events in quadrant A | 3,261,559 | 685,010 |
| Events in quadrant B | 3,409,191 | 701,070 |
| Events in quadrant C | 3,295,134 | 659,777 |
| Events in quadrant D | 4,465,013 | 631,058 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13742 | 2 |
| B | 0 | 14093 | 2 |
| C | 0 | 13681 | 2 |
| D | 0 | 17570 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6406 | 56 | 0.874180% |
| B | 6406 | 96 | 1.498595% |
| C | 6407 | 88 | 1.373498% |
| D | 6407 | 154 | 2.403621% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7536 | 6407 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7536 | 6407 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7537 | 6408 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7537 | 6408 | 115 | 115 | 1.53% | 1.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 47588 | 280.2 | 832 | 817 | 166.9 |
| A | 13 | 254 | 11726 | 65.35 | 832 | 817 | 166.9 |
| A | 3 | 137 | 8047 | 43.31 | 832 | 817 | 166.9 |
| B | 10 | 246 | 80274 | 501.29 | 834 | 812 | 158.5 |
| B | 0 | 183 | 25602 | 156.39 | 834 | 812 | 158.5 |
| B | 12 | 111 | 19368 | 117.06 | 834 | 812 | 158.5 |
| C | 14 | 238 | 131101 | 697.52 | 800 | 808 | 186.8 |
| C | 3 | 233 | 30056 | 156.58 | 800 | 808 | 186.8 |
| C | 2 | 114 | 14833 | 75.08 | 800 | 808 | 186.8 |
| D | 8 | 195 | 705353 | 3769.76 | 792 | 774 | 186.9 |
| D | 1 | 52 | 583178 | 3116.08 | 792 | 774 | 186.9 |
| D | 2 | 250 | 55739 | 294.08 | 792 | 774 | 186.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
