| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_099T01_9000004184_29141cztM0_level2.evt | modeM0/AS1A10_099T01_9000004184_29141cztM0_level2_quad_clean.evt |
| Size (bytes) | 592,683,840 | 103,648,320 |
| Size | 565.2 MB | 98.8 MB |
| Events in quadrant A | 3,721,256 | 671,837 |
| Events in quadrant B | 3,849,497 | 686,261 |
| Events in quadrant C | 3,766,109 | 651,867 |
| Events in quadrant D | 6,111,991 | 614,689 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15881 | 2 |
| B | 0 | 16172 | 2 |
| C | 0 | 15807 | 2 |
| D | 0 | 23238 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7387 | 95 | 1.286043% |
| B | 7388 | 156 | 2.111532% |
| C | 7388 | 129 | 1.746075% |
| D | 7388 | 381 | 5.157011% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9237 | 7389 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9238 | 7390 | 0 | 0 | 0.00% | 0.00% |  |
| C | 9238 | 7390 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9238 | 7390 | 369 | 369 | 3.99% | 4.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 49407 | 254.65 | 950 | 928 | 190.4 |
| A | 13 | 254 | 12887 | 62.82 | 950 | 928 | 190.4 |
| A | 3 | 137 | 9594 | 45.52 | 950 | 928 | 190.4 |
| B | 0 | 190 | 38645 | 205.51 | 948 | 922 | 183.6 |
| B | 0 | 183 | 38116 | 202.63 | 948 | 922 | 183.6 |
| B | 10 | 246 | 31491 | 166.54 | 948 | 922 | 183.6 |
| C | 14 | 238 | 145833 | 677.99 | 912 | 917 | 213.7 |
| C | 3 | 233 | 50329 | 231.17 | 912 | 917 | 213.7 |
| C | 2 | 114 | 17617 | 78.13 | 912 | 917 | 213.7 |
| D | 1 | 52 | 1705900 | 7875.92 | 903 | 881 | 216.5 |
| D | 8 | 195 | 860976 | 3973.0 | 903 | 881 | 216.5 |
| D | 7 | 80 | 68420 | 311.98 | 903 | 881 | 216.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
